10-24
_10
PLC device
Response message
High byte
Low byte
D24004 Reserved Sub-index
D24005 Datum 1 Datum 0
D24006 Datum 3 Datum 2
D24007~D24031 Reserved
 Status code:
The following table lists the status code values in the response message.
Status code
Explanation
0
No data transmission request
1 SDO message transmission succeeds.
2
SDO message is being transmitted.
3
Error: SDO transmission time-out
4
Error: Illegal command code
5
Error: the length of the transmitted data is illegal.
6
Error: the length of the response data is illegal.
7
Error: Equipment to be sent messages is busy.
8
Error: Illegal type
9
Error: Incorrect node address
0A
Error message (See the error code for SDO response message)
0B-FF Reserved
 ResID: the same as the request ID in the request message.
 Size: the length of the message data, maximum of 20 bytes. The unit is bytes. When writing, the
maximum is four; the data length is decided by the data type of index and subindex when reading.
 Node ID: the node address of the target equipment on CANopen network.
 Type: in the SDO response message, 43 (Hex) refers to reading four bytes of data; 4B (Hex) refers to
reading two bytes of data; 4F (Hex) refers to reading one byte of data; 60 (Hex) refers to writing 1/2/4
byte(s) of data; 80 (Hex) refers to stopping SDO command.
Example 1: write 010203E8 (Hex) to (Index_subindex) 212D_0 in slave of No. 3 through SDO; the data type of
(Index_subindex) 212D_0 is double words (32 bits).
 Request data:
PLC device
Request message
High byte(Hex) Low byte(Hex)
D25000
Message
Header
ReqID=01
Command =01
D25001
Reserved =0
Size =8
D25002
Type =02
Node ID =03
D25003
Message
data
Main index high byte =21
Main index low byte =2D
D25004
Reserved =0
Subindex =0
D25005
Datum 1=03
Datum 0=E8
D25006
Datum 3=01 Datum 2=02
