Chapter 12 CPU Module Operating Principle
12-5
12_
 Relationship between the operating modes and tasks
Mode Loop task Interrupt task
STOP Execution of a loop tasks stops.
Execution of an interrupt task
stops.
RUN
 The tasks that have not been executed are in the
HALT state.
 If a task is active, or the instruction TKON is
executed, the task executes.
 If a task is not active, or the instruction TKOFF
executes, the task does not execute.
If the condition of the interrupt is
met, the interrupt task executes.
 Relationship between changing modes and the program memory
Change of the mode Non-latched area Latched area
STOP→RUN
Data is cleared or retained depending
on your setting.
The data is retained.
RUN→STOP The data is retained. The data is retained.
