Delta DVP-ES3 Series Hardware Manual

DVP-ES3/EX3/SV3/SX3 Series Hardware and Operation Manual
2-6
_2
 Electrical specifications for the inputs on DVP-ES3 Series PLC CPU. The signals passing through
the inputs are 24 VDC signals.
Model
Item
DVP32ES311T
DVP32ES300T
DVP32ES300TEC
DVP32ES300R
DVP48ES300T
DVP48ES300R
DVP64ES300T
DVP64ES300R
DVP80ES300T
DVP80ES300R
Number of inputs
16 (X0 ~ X17)
24 (X0 ~ X27)
32 (X0 ~ X37)
40 (X0 ~ X47)
Connector type
Removable terminal blocks
Input type
Digital input
Input form
Direct current (sinking or sourcing)
Input voltage/ current
24VDC
S/S, S/S0: 80mA; S/S1: 120mA; X0 ~ X47: 5mA
Action
level
OFF→ON
>15 VDC
ON→OFF
<5 VDC
Response
time
OFF→ON
X0 ~ X7: 1.
5μs
X10 ~ X17: 50μs
X20～X47: 10ms
ON→OFF
Maximum input
frequency
X0 ~ X7: 200
kHz
X10 ~ X17: 10kHz
X20～X47: 50Hz
Input impedance
X0 ~ X7: 3
.9kΩ
X10 ~ X47: 5.6kΩ
Input isolation
500 VAC
Input display
When the optocoupler is driven, the input LED indicator is ON.
