DVP-ES3/EX3/SV3/SX3 Series Hardware and Operation Manual
2-12
LED indocaor descriptions
1 Output type
R: Relay output
2 Input/Output LED
If there is an input signal, the input LED indicator is ON.
If there is an output signal, the output LED indicator is ON.
3
CAN communication LED
(applicable to ES3 Series)
ON: In communication
LINK/ACT E1, E2
communication LED
(application to EX3 /
ON: Communication port is connected.
Blinking: Data in transmission
OFF: Communication port is NOT connected.
Power status of the CPU module
Run LED
Operating status of the module
ON: PLC program is running.
OFF: PLC program is stopped.
Blinking: PLC program detects an error
Error LED
Error status of the module
Blinking slowly (1 second ON, 3 seconds OFF): Warning
Blinking (0.5 seconds ON and OFF): Error
Blinking rapidly (0.2 seconds ON and OFF): Low voltage
Communication status
OFF: No communication
Blinking: In communication
COM1/COM2
CAN communication LED
(applicable to EX3)
ECAT communication LED
(applicable to
32ES300TEC)
EtherCAT status
Green LED ON: Communication card is working normally. (Slaves
are all in Operational State.)
Red LED ON: The connection between Master and Slave is NOT
connected.
Red LED Blinking (2 seconds ON and OFF): Slave is NOT
connected.
Red LED Blinking (0.5 seconds ON and OFF): Slave status is
abnormal.
OFF: EtherCAT Master is NOT activated.
LINK/ACT LED (applicable
to ES3)
ON: Communication port is connected.
Blinking: Data in transmission
OFF: Communication port is NOT connected.
5 RJ45 communication port
An interface for RJ45 communication
ES3 is built with a single RJ45 port (Ethernet);
EX3 is built with a dual RJ45 ports (Ethernet);
32ES300TEC is built with two RJ45 ports: #1 EtherCAT port,
Removable terminal blocks
Connects the module and the wiring module
Secures the module on the set
9 RUN/STOP
RUN: executes the program
