VFD-MS300/MH300 EtherNet/IP Communication Card CMM-EIP01
CMM-EIP01 Operation Manual
24
Object Instance Attributes Definition
Initial
value
R/W Size Note
0x02
Frequency
command
(XXX.XX Hz)
0 RW U16
0x03 Other trigger 0 RW U16
Bit 0 1: E.F. ON
0x20 Bit 1 1: Reset command
0x300
Bit 2 1: External interruption (B.B) ON
Bit
15~3
Reserved
0x21
0x00 Number 10 R U8
0x01 Error code 0 R U16
High byte: Warn code
Low byte: Error code
0x02 VFD status 0 R U16
Bit 1~0
00B: VFD has stopped
01B: VFD is decelerating
10B: VFD is in standby
mode
11B: VFD is in operation
Bit 2 1: JOG command
Bit 4~3
00B: Clockwise rotation
01B: Counterclockwise to
clockwise rotation
status
10B: Clockwise to
counterclockwise
rotation status
11B: Counterclockwise
rotation
Bit 7~5 Reserved
Bit 8
1: Main frequency source is
the communication
interface
Bit 9
1: Main frequency source is
the analog signal input
Bit 10
1: Operational command
comes from the
communication interface
Bit 11 1: Locking parameters
Bit 12
1: Digital keypad copies the
parameter functions
Bit 15~13 Reserved
0x03
Frequency
command
(XXX.XX Hz)
0 R U16
0x04
Output
frequency
(XXX.XX Hz)
0 R U16
0x05
Output current
(XX.X A)
0 R U16
0x06
DC bus voltage
(XXX.X V)
0 R U16
0x07
Output voltage
(XXX.X V)
0 R U16
