VFD-MS300/MH300 EtherNet/IP Communication Card CMM-EIP01
CMM-EIP01 Operation Manual
25
Object Instance Attributes Definition
Initial
value
R/W Size Note
0x300
0x21
0x08
Current execution speed of the multi-section
command
0 R U16
0x09 Reserved 0 R U16
0x0A Display counter value (c) 0 R U16
0x0B Output power factor angle (XX.X°) 0 R U16
0x0C Output torque (XXX.X %) 0 R U16
0x0D Actual motor rotational speed (rpm) 0 R U16
0x0E
PG feedback pulse count
(0–65535)
0 R U16
0x0F PG2 pulse command count (0–65535) 0 R U16
0x10 Output power (X.XXX kWh) 0 R U16
0x17 Multi-function display (Pr. 00-04) 0 R U16
0x22
0x00 Reserved 0 R U16
0x01 Displays drive's output current 0 R U16
0x02 Counter value 0 R U16
0x03 Actual output frequency 0 R U16
0x04 DC-BUS voltage 0 R U16
0x05 Output voltage 0 R U16
0x06 Power factor angle 0 R U16
0x07 Displays U, V, W power output kW 0 R U16
0x08
Motor speed estimated by the VFD or returned by
the encoder; unit: rpm
0 R U16
0x09
Output positive/negative torque of VFD %
(t 0.0: positive torque; - 0.0: negative torque)
0 R U16
0x0A
Displays PG feedback (refer to Pr. 00-04 as
indicated in Note 1)
0 R U16
0x0B
A
fter the functions of PID has been activated, the
PID feedback value will be displayed;
unit: %
0 R U16
0x0C
Displays signal values of AVI analog input ports;
0–10V corresponds to 0–100% (refer to
parameter 00-04 as indicated in Note 2)
0 R U16
0x0D
Displays signal values of ACI analog input ports;
4–20mA/0–10V corresponds to 0–100% (as
indicated in Note 2)
0 R U16
0x0E
Displays signal values of AUI analog input ports;
-10V–10V corresponds to -100–100% (as
indicated in Note 2)
0 R U16
0x0F IGBT power module temperature °C 0 R U16
0x10 Temperature of VFD capacitor °C 0 R U16
0x11
On / Off status of digital input; see parameter
02-12 (refer to Note 3 for parameter 00-04)
0 R U16
0x12
On / Off status of digital output; see parameter
02-18 (refer to Note 4 for parameter 00-04)
0 R U16
0x13
Current execution speed of the multi-section
command
0 R U16
