VFD-MS300/MH300 EtherNet/IP Communication Card CMM-EIP01
CMM-EIP01 Operation Manual
27
EtherNet/IP Remote Input / Output mapping address
Object Instance Attributes Attributes Description
0x300 0x26
0x00 R Each bit corresponds to a different terminal input contact
0x01 R Each bit corresponds to a different terminal input contact
0x02~0x3F R Reserved
0x40 RW Each bit corresponds to a different terminal output contact
0x42~0x5F R Reserved
0x60 R AVI proportion
0x61 R ACI proportion
0x63~0x9F R Reserved
0xA0 RW AFM1 output proportion
Class
0x300
Instance
0x26
Attribute
0x00
Bit 0 Bit 1 Bit 2 Bit 3 Bit 4 Bit 5 Bit 6 Bit 7 Bit8 Bit9 Bit10 Bit11 Bit12 Bit13 Bit14 Bit15
1 MI1 MI2 MI3 MI4 MI5 MI6 MI7
2 MI10 MI11 MI12
1: Control broad I/O (Standard)
2: Add external card, EMM-D33A (only for MH300)
Object x300
instance 0x26
attribute 0x40
Bit 0 Bit 1 Bit 2 Bit 3 Bit 4 Bit 5 Bit 6 Bit 7 Bit8 Bit9 Bit10 Bit11 Bit12 Bit13 Bit14 Bit15
1 RY1 MO1 MO2
2 MO10 MO11 MO12
3 RY10 RY11
4 RY10 RY11 RY12
1: Control broad I/O (Standard)
2: Add external card, EMM-D33A (only for MH300)
3: Add external card, EMM-R2CA (only for MH300)
4: Add external card, EMM-R3AA (only for MH300)
