ENGLISH
Auto Setup
Optimize settings for speakers
in
use.
'N·O.
•
Do
not disconnect the setup microphone until the auto setup
procedure
is
completed.
• When using headphones, unplug the headphones before starting
the auto setup procedure.
'n·O.
Do not change the speaker connections or subwoofer volume after
"Step 1".
I
1spkr
)
Fro
n t S p .
Yes
Center
Sp.
S u
bwo
0
fer
Yes
Sur
r 0 u n d S
p.
Yes
S.
Ba c k Sp .
Yes
[fNext~
Ret
r y
~
Auto
Setup
Audyssey
Mu
I
tEQ
Front
Sp.
~
A
~
Amp
Assign
[fStart~
Cancel
~
• Menu screen •
CD
( Step 1 : Speaker Detection
• If the result differs from the actual connection status or
an
error
message appears, use
\l
to on-screen
display"
Retry
.....
"
and
then
press
<I
to repeat the measurement.
• If the result still differs from the actual connection status after
re-
measurement or the error message still appears, it
is
possible that
the speakers are not connected properly. Turn the AVR-2309CI
off, check the speaker connections and repeat the measurement
process from the beginning.
The speaker connection and polarity are detected at the first
measurement position (main listening position). The following
attributes are also determined at this time: "Speaker Size", "Speaker
Distance", "Channel Level", "Crossover Frequency".
CD
Press
6.
V to select "Start
.....
", then press
<I.
(1)
Press
6.
to
select "Next
.....
", then press
<I.
•
To
cancel the measurements, press
<I.
About the Auto Setup
The Audyssey MultEO auto setup function detects the presence of
each speaker
and
automatically calculates the speaker
size,
channel
level, distance,
and
optimal crossover frequency setting. Audyssey
MultEO corrects acoustical distortions within the listening area.
Before starting, connect
and
position
all
of your speakers.
Once started, MultEO will
playa
series of test tones through
each
speaker.
'Nti
••
• Loud test sounds may
be
played during Audyssey MultEO automatic
speaker setup. This
is
part of normal operation. If there
is
background
noise
in
room, these test signals will increase
in
volume.
•
Do
not stand between the speakers and setup microphone or allow
obstacles
in
the path while the measurements are being made. This
will cause inaccurate readings.
• Make the room
as
quiet
as
possible. Background noise
can
disrupt
the room measurements. Close windows, silence cell phones,
televisions, radios, air conditioners, fluorescent lights, home
appliances, light dimmers, or other devices
as
measurements may
be
affected by these sounds.
Cell
phones should
be
placed away from
all
audio electronics during
the measurement process
as
Radio Frequency Interference
(RFI)
may cause measurement disruptions (even if the cell phone
is
not
in
use).
• Operating
MASTER
VOLUME
during the measurements will cancel
the measurements
If
an
error message appears during the measurements,
check"
Error
Messages", take the advised action, then start the measurements
again
(D:2Fpage
28).
Front Speaker
The front speaker to
be
measured
can
be
selected ahead of time
here.
)
)
)
)
)
t
t
t
t
o
Auto
Setup
The settings found at this stage are applied automatically.
[Auto setup flow]
( Step
1:
Speaker Detection
( Step
2:
Measurement
( Step
3:
Calculation
( Step
4:
Check
( Step
5:
Store
[Selectable items]
o :Output test tone from front speakers
A.
B : Output test tone from front speakers
B.
A+B
: Output test tone from front speakers A and
B.
DAmp
Assign
Advanced
setting:
changes power amplifier assignment.
For details, refer to
"Amp
Assign"
(D:2Fpage
35).
26
