Denon AVR-3808CI Service Manual

127
AVR-3808CI / AVR-3808 / AVC-3808
Except for Japan model
1U-3802E P.SUPPLY P.W.B. UNIT ASS'Y (EU,EC model)
1U-3802F P.SUPPLY P.W.B. UNIT ASS'Y (BKE2,SRE2,E2A model)
1U-3802G P.SUPPLY P.W.B. UNIT ASS'Y (EUT model)
1U-3802H P.SUPPLY P.W.B. UNIT ASS'Y (E1C model)
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
TR401,402 00D 273 0468 907 KTC3199-GR-AT/P
TR803 00D 271 0301 903 KTA1268-BL-AT/P
TR805-811 00D 271 0301 903 KTA1268-BL-AT/P
TR813-816 00D 271 0301 903 KTA1268-BL-AT/P
TR817-819 00D 273 0471 907 KTC3206-Y-AT/P
TR821-824 00D 273 0471 907 KTC3206-Y-AT/P
TR825-827 00D 271 0314 903 KTA1024-Y-AT/P
TR829-832 00D 271 0314 903 KTA1024-Y-AT/P
TR833-835 00D 273 0471 907 KTC3206-Y-AT/P
TR837-840 00D 273 0471 907 KTC3206-Y-AT/P
TR901,902 00D 271 0301 903 KTA1268-BL-AT/P
D401 00D 276 0704 903 1SR35-400A(T93X)
D403-410 00D 276 0704 903 1SR35-400A(T93X)
D411,412 00D 276 0401 905 1SS133T77 (TAPE)
D413-415 00D 276 0704 903 1SR35-400A(T93X)
D417 00D 276 0305 001 S4VB20
D501 00D 276 0305 001 S4VB20
D504 00D 276 0305 001 S4VB20
D505,506 00D 276 0704 903 1SR35-400A(T93X)
D801-803 00D 276 0401 905 1SS133T77 (TAPE)
D805-811 00D 276 0401 905 1SS133T77 (TAPE)
D813-819 00D 276 0401 905 1SS133T77 (TAPE)
D821-826 00D 276 0401 905 1SS133T77 (TAPE)
RESISTORS GROUP
R404 00D 244 2050 904 RS14B3A220JNBST(S)
R405 00D 244 2064 974 RS14B3A330JNBST(S)
R410 00D 242 2009 001 RC1/2 225K B(UL) EU,EC
R825-827 00D 241 2379 987 RD14B2E102JNBST
R829-832 00D 241 2379 987 RD14B2E102JNBST
R849-851 00D 241 2379 987 RD14B2E102JNBST
R853-856 00D 241 2379 987 RD14B2E102JNBST
R865-867 00D 244 2671 914 RS14B3D153JNBST(S)
R869-872 00D 244 2671 914 RS14B3D153JNBST(S)
R873-875 00D 241 2378 946 RD14B2E271JNBST
R877-883 00D 241 2378 946 RD14B2E271JNBST
R885-891 00D 241 2378 946 RD14B2E271JNBST
R893-896 00D 241 2378 946 RD14B2E271JNBST
CAPACITORS GROUP
C402 00D 254 4524 943 CE04W1H010MT SMG/RE3
C403 00D 254 4442 708 CE04W1C682MC (SMG)
C405 00D 254 4524 943 CE04W1H010MT SMG/RE3
C407 00D 255 1279 951 CQ93M1H104JT(B)
C408,409 00D 253 8022 707 CK45F2EAC103MC
C410 00D 255 1279 951 CQ93M1H104JT(B)
C411 00D 254 4523 724 CE04W1V472MC SMG/RE3
C412 00D 255 1279 951 CQ93M1H104JT(B)
C501 00D 256 1042 903 CF93A2E104KT
C502,503 00D 255 1279 951 CQ93M1H104JT(B)
C504,505 00D 254 6258 000 CE68W1V822M
C513-515 00D 255 1279 951 CQ93M1H104JT(B)
C516,517 00D 254 4428 706 CE04W1V222MC (SMG)
C518,519 00D 254 4761 706 CE04W1C153MC(SMQ)
C801-803 00D 254 4524 985 CE04W1H100MT SMG/RE3
C804 00D 254 4524 943 CE04W1H010MT SMG/RE3
C805-808 00D 254 4524 985 CE04W1H100MT SMG/RE3
