Denon AVR-3808CI Service Manual

135
AVR-3808CI / AVR-3808 / AVC-3808
Except for Japan model
C709 nsp CK73B1H102KT +1608
C710 00D 254 4666 005 CE04W0H105ZC(FG)
C711,712 nsp CC73CH1H100DT +1608
C713 00D 254 4533 934 CE04W0J221MT SMG/RE3
C714 nsp CK73B1H102KT +1608
C715 nsp CK73B1E104KT +1608
C716 00D 254 4536 928 CE04W1A101MT SMG/RE3
C801,802 nsp CK73B1E104KT +1608
C901 00D 254 4524 985 CE04W1H100MT SMG/RE3 Except for E1C
C902 nsp CK73B1H102KT +1608 Except for E1C
C905 nsp CC73CH1H101JT +1608 Except for E1C
C906,907 nsp CK73B1H102KT +1608 Except for E1C
C909-911 nsp CK73B1H102KT +1608 Except for E1C
C912 00D 254 4524 985 CE04W1H100MT SMG/RE3 Except for E1C
C913-914 nsp CC73CH1H220JT BKE2,SRE2,E2A
C915 nsp CC73CH1H331JT BKE2,SRE2,E2A
C916 nsp CC73CH1H561JT BKE2,SRE2,E2A
C917 00D 254 4524 985 CE04W1H100MT SMG/RE3 BKE2,SRE2,E2A
C918 nsp CK73B1E104KT +1608 BKE2,SRE2,E2A
C919 00D 254 4524 985 CE04W1H100MT SMG/RE3 BKE2,SRE2,E2A
C923,924 00D 254 4524 985 CE04W1H100MT SMG/RE3 Except for E1C
C927-930 00D 254 4524 985 CE04W1H100MT SMG/RE3 Except for E1C
C929-930 00D 254 4524 985 CE04W1H100MT SMG/RE3 E1C
C933,934 00D 254 4524 985 CE04W1H100MT SMG/RE3
OTHERS PARTS GROUP
CW055 nsp 5P PH CONN.CORD E1C
CW068 nsp 6P CON.SOCKET(TUC-P
CW071 nsp 7P CON.SOCKET(TUC-P
CW081 nsp 8P CON.SOCKET(TUC-P)
CW110 nsp 11P CON.SOCKET TUC-P
CW152-155 nsp 15P CON.SOCKET TUC-P
CW156 nsp 15P SOCKET(9120)
CW161 nsp 16P CON.SOCKET TUC-P
CX042 nsp 4P PIN HEADER(9120)
CX055 nsp 5P CONN BASE(KR-PH) E1C
CX082 nsp 8P CON BASE(TUC-P)
CX083 nsp 8P PIN HEADER(9120)
CX102 nsp 10P CON.BASE TUC-P
CX136 nsp 13P ZR CON BASE
CX142 nsp 14P CON.BASE TUC-P
CX150 00D 205 0736 076 15P FFC CON.BASE Except for E1C
CX153,154 nsp 15P CON.BASE TUC-P
CX159 nsp 15P PIN HEADER(9120)
CX161,162 nsp 16P CON.BASE TUC-P
CX191 nsp 19P CON.PLUG(TWG-P)
CX251 00D 205 1352 048 25P-FFC-BASE(TOC-J)
CX271 00D 205 1352 064 27P-FFC-BASE(TOC-J)
JK101 00D 204 8747 019 4P-PIN-JACK(NI)
JK102-107 00M YJ0 6031 950 RJ-1073_09-0331A
JK501 00D 204 8747 019 4P-PIN-JACK(NI)
JK502,503 00M YJ0 6031 950 RJ-1073_09-0331A
JK705 00D 204 8562 016 2P PIN JACK(S-GND) E1C
L101-102 00D 235 9003 002 FTZ CHOKE COIL BKE2,SRE2,E2A,E1C
TP701 00D 205 1393 010 12P FFC BASE(9610SA)
X701 00D 399 0594 005 X'TAL(30MHZ)
X901 00D 399 0178 007 X-TAL(4.332MHZ) BKE2,SRE2,E2A
Ref. No. Part No. Part Name Remarks Q'ty New
