Denon AVR-3808CI Service Manual

138
AVR-3808CI / AVR-3808 / AVC-3808
AVC-3808 : Japan model
PARTS LIST OF P.W.B. UNIT
AVC-3808 : Japan model
＊本表に"nsp" と記載されている部品は供給できません。
＊ Parts for which "nsp" is indicated on this table cannot be supplied.
＊本表に記載されている部品は、補修用部品のため製品に使用している部品とは一部、形状、寸法などが異なる場合があります。
＊ The parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
1U-3799J DIGITAL P.W.B. UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC101-103 nsp LC89057W-VF4A
IC107 nsp SN65LVDS32PW +REF
IC108 nsp SN65LVDS1DBVR
IC151 nsp EPM570F256C5N
IC152 nsp ICS570BLFT
IC155 nsp TC74VHC244FT
IC201 nsp ADSP21366KBCZ1AA1134
IC202 nsp EN5312QI-T
IC203 nsp SN74LVC139APWR +REF
IC204,205 nsp TC74VHC573FT
IC206 nsp DSP1 ROM SUB ASSY S29AL016D90TFI020#:GEN 8371
IC207 nsp CY7C1049DV33-10ZSXI
IC251 nsp ADSP21367KBPZ2A1134
IC254 nsp W9864G2GH-7
IC255 nsp DSP2 ROM SUB ASSY S29AL016D90TFI020#:GEN 8372
IC301 nsp PCM1804 +REF
IC302-305 nsp PCM1791ADBR +REF
IC306 nsp UPC2933BT1D-E1-AT
IC307-309 nsp NJM2115M-TE1 +C
IC310-314 nsp SA5532ADR
IC351 nsp AK4385ET
IC353 nsp BA15218F-DXE2 +C
IC402 nsp MICROSMD175F
IC404 nsp RTL8201CP
IC405 nsp BCOIC-DM850E-CQL
IC408 nsp DM850 ROM SUB ASSY S29GL064A90TFIR40:GEN 8562
IC409 nsp W9812G6GH-6
IC410 nsp LM2832XMY
IC411 nsp FSUSB22
IC412 nsp PQ070XZ01ZP +C
IC413 nsp MICROSMD175F
IC415 nsp TC7W66FK
IC416 nsp SN74LVC2G14DBVR
IC501 nsp UPC2925BT1D-E1-AT
IC510 nsp SII9185CTU
IC511 nsp AZ1117H-1.8TRE1
IC554 nsp SII9135CTU
IC555 nsp UPC2918BT1D-E1-AT
IC601 nsp EP2C35F484C8N
IC602 nsp W9425G6DH-5
IC603 nsp FCXO-03L(27.000MHz)
IC604 nsp UPC2925BT1D-E1-AT
IC605 nsp FCXO-05(48.0MHZ)
IC606 nsp M25P64-VMF6TG(DE96)
IC607 nsp LP2995M
IC608 nsp TC74VHC244FT
IC609 nsp EPCS16SI16N
IC610 nsp LM2832XMY
IC611 nsp UPC2925BT1D-E1-AT
IC612,613 nsp CDCVF2505PWR
IC701 nsp UPC2918BT1D-E1-AT
IC702 nsp SII9134CTU
IC703 nsp UPC2925BT1D-E1-AT
IC704 nsp SN74LV74APW-EL2 +C
IC751 nsp UPC2918BT1D-E1-AT
IC752 nsp SII9134CTU
IC753 nsp UPC2925BT1D-E1-AT
