Denon AVR-3808CI Service Manual

36
AVR-3808CI / AVR-3808 / AVC-3808
※ Unless specified, 1U-3800-1 A.VIDEO UNIT part.
N
Input
S
Check ± 5VA and +5VD.
+5VA : CW082-3,4pin
-5VA : CW082-1,2pin
+5VD : CW132-1pin
NG
To troubleshooting 1.1 Power not turn
on.
OK
Check input/output of analog SW.
Input Y : IC412-13pin
Input C : IC418-13pin
Output Y : IC412-3pin
Output C : IC418-3pin
NG
Check analog SW settings.
IC412-9,10,11pin : L(0V)
IC412-6pin : L(0V)
IC418-9,10,11pin : L(0V)
IC418-6pin : L(0V)
NG
Check IC505,IC508 and CW132
soldering, or DIGITAL UNIT flaw.
OK
OK
Check soldering of IC412 and IC418.
Check input/output of AMP.
Input Y : IC407-3pin
Input C : IC408-3pin
Output Y : IC407-1pin
Output C : IC408-1pin
NG
Check soldering of IC407, IC408 and
surrounding parts.
OK
Check input/output of analog SW.
Input Y : IC414-3pin
Input C : IC414-13pin
Output Y : IC414-4pin
Output C : IC414-14pin
NG
Check analog SW settings.
IC414-9,10,11pin : H(+5V)
NG
Check IC505 and CW132 soldering, or
DIGITAL UNIT flaw.
OK
OK
Check soldering of IC414.
Check input/output of AMP.
Input Y : IC402-3pin
Input C : IC402-5pin
Output Y : IC402-1pin
Output C : IC402-7pin
NG
Check soldering of IC402.
OK
Check cable between main unit and
monitor or Check monitor.
※ 特に記載がない場合は 1U-3800-1A.VIDEOUNITの部品です。
N
入力
S
± 5VA，+5VDの確認
+5VA:CW082-3,4pin
-5VA:CW082-1,2pin
+5VD:CW132-1pin
NG
1.1 電源が入らないのﾄﾗﾌﾞﾙｼｭｰﾃｨﾝｸﾞへ
OK
ｱﾅﾛｸﾞ SW の入出力確認
入力 Y:IC412-13pin
入力 C:IC418-13pin
出力 Y:IC412-3pin
出力 C:IC418-3pin
NG
ｱﾅﾛｸﾞ SW の設定確認
IC412-9,10,11pin:Ｌ(0V)
IC412-6pin:Ｌ(0V)
IC418-9,10,11pin:Ｌ(0V)
IC418-6pin:Ｌ(0V)
NG
IC505,IC508,CW132 のﾊﾝﾀﾞ付け確認
もしくは DIGITALUNIT の不具合
OK
OK
IC412,IC418 のﾊﾝﾀﾞ付け確認
AMP の入出力確認
入力 Y:IC407-3pin
入力 C:IC408-3pin
出力 Y:IC407-1pin
出力 C:IC408-1pin
NG
IC407,IC408 及び周辺部品の
ﾊﾝﾀﾞ付け確認
OK
ｱﾅﾛｸﾞ SW の入出力確認
入力 Y:IC414-3pin
入力 C:IC414-13pin
出力 Y:IC414-4pin
出力 C:IC414-14pin
NG
ｱﾅﾛｸﾞ SW の設定確認
IC414-9,10,11pin:H(+5V)
NG
IC505,CW132 のﾊﾝﾀﾞ付け確認
もしくは DIGITALUNIT の不具合
OK
OK
IC414 ﾊﾝﾀﾞ付け確認
AMP の入出力確認
入力 Y:IC402-3pin
入力 C:IC402-5pin
出力 Y:IC402-1pin
出力 C:IC402-7pin
NG
IC402 のﾊﾝﾀﾞ付け確認
OK
本体 -MONITOR間のｹｰﾌﾞﾙ
もしくはMONITOR の確認
