18
7.5.2.3.1 Description - Interface parameters (FB13)
Designation Type Data type Description
I_Addr1 INT
Input address from the hardware configuration
e.g. 256
I_Addr2 INT
Input address from the hardware configuration
e.g. 320
I_Addr3 INT
Input address from the hardware configuration
e.g. 384
I_Addr4 INT
Input address from the hardware configuration
e.g. 448
O_Addr1 INT
Output address from the hardware configuration
e.g. 256
O_Addr2 INT
Output address from the hardware configuration
e.g. 320
O_Addr3 INT
Output address from the hardware configuration
e.g. 384
O_Addr4 INT
Output address from the hardware configuration
e.g. 448
Control
IN
Structure
of UDT 31
Data structure of the control signals
State
Structure
of UDT 32
Data structure of the status signals
Data
OUT
Structure
of UDT 33
Data structure of the screw data
Table 3: Description - Interface parameters (FB13)
