80
17.7.3
GRAPH10 - Curve overlapping
Figure 44:
GRAPH10E
The GRAPH10(E) program can be
downloaded free of charge vi
a the web interface of the
sequence controller AST6. However, the use of
the curve overlapping is subject to cost.
Designation
Part no.
Graph 10 Software release key Curve overlapping
202698
79
81
