51
Parameter Description
Fieldbus Available Specifies whether a fieldbus module is available.
Control via the
I/O interface
Activates the control via the I/O interface if a fieldbus
module is available.
Table 8: Adjustable Parameter
9.1.2 Special parameters for fieldbus systems (optional)
9.1.2.1 Profibus
Parameter Description
Profibus address Address under which the AST6 is accessible in the
Profibus.
Table 9: Configurable Profibus parameters
9.1.2.2 Profinet
Parameter Description
IP address The IP address via which the AST6 is accessible in
the network via Profinet.
Net mask It designates the network segment in which the AST6
sequence controller lies.
Gateway The IP address of the gateway for the network
segment in which the AST6 sequence controller lies.
Station name Station name of the AST6 in the Profinet.
Table 10: Configurable Profinet parameters
9.1.2.3 Ethernet IP
Parameter Description
IP address The IP address via which the AST6 is accessible in
the network via Ethernet IP.
Net mask It designates the network segment in which the AST6
sequence controller lies.
Gateway The IP address of the gateway for the network
segment in which the AST6 sequence controller lies.
DHCP If DHCP is active, the network addresses set /
displayed are not valid. They are assigned via a
DHCP server.
BOOTP If BOOTP is active, the network addresses set /
displayed are not valid. They are assigned via
BOOTP.
Table 11: Configurable Ethernet IP parameters
9.1.2.4 Ethercat
No settings are necessary.
