Blitz-DT9 User Manual
- 9 -
. .
0%
00:00
00:00
MODEL01
NORM
00:00:57
45%
Battery Indicator
System Timer
Model Type
Throttle Trim
Model Name
L Trim
Timer（1，2）
Elevator Trim
Flight Mode
R Trim
Rudder Trim
Current Position
（Based on the standard
servo movement）
1.
2.
....
Aileron Trim
 Note:
 When the Stick Mode is set to MODE 1, the positions of trims are shown in
the figure.
 For details about the flight modes, please refer to Flight Mode (Page 16).
Receiver
This section is the introductions of DETRUM RXC9M Receiver. If you choose
other receivers, please refer to the instructions of the other receivers.
Specifications
Parameters
RXC9M Specifications
Type
2.4GHz, 9-channel receiver
Sensitivity
-97dBm
Frequency interval
larger than or equal to 4MHz
Power supply
3.6V~16V
Weight
10g
Size
42.6mm*27.4mm*12.9mm
Features
 Adopting 2.4GHz direct sequence spread spectrum (DSSS) and multiple
frequency-hopping spread spectrum (FHSS) technology, the receiver has
high sensitivity and strong anti-interference capability.
 By using diversity antenna, can automatically switch the signals to ensure the
stability of the received signal.
 Each transmitter has an individually assigned, unique ID code. Once the
binding is made, the ID code is stored in the receiver and no further binding is
necessary after restarting the receiver.
 When the aircraft flies out of range, the receiver cannot receive a valid RF
signal from the transmitter and will move the servos to predefined position.
 Working with the optional telemetry module and sensors, RXC9M can
