Blitz-DT9 User Manual
- 52 -
For the descriptions of each parameter, Please refer to Aileron Curve [AIL
Curve](Page 44).
After setting the helicopter’s pitch curve, you can select the hold, normal, or
acrobatic pitch curve by using throttle hold switch and acrobatic flight switch.
Aileron Curve [AIL Curve]
Please refer to Aileron Curve [AIL Curve] (Page 44).
Elevator Curve [ELE Curve]
Please refer to Elevator Curve [ELE Curve] (Page 45).
Throttle Curve [THR Curve]
This function is used to adjust throttle servo operation in response to throttle stick
operation. The servo position can be set independently for a maximum of 9 point
positions. You can set throttle curve for the helicopter's NORM (normal) and ACR
(acrobatic) flight mode respectively.
NORM THR Curve (Throttle Curve D0): It is used to adjust throttle servo
operation in response to throttle stick operation when the helicopter is in
normal flight mode.
ACR THR Curve (Throttle Curve D1): It is used to adjust throttle servo
operation in response to throttle stick operation when the helicopter is in
acrobatic flight mode.
Setting Method:
1. In the Model Parameter menu, roll the scroll wheel to select THR Curve, and
then press the scroll wheel to enter the THR Curve D0 setting interface.
Roll the scroll wheel to select THR-D0 and edit this item that user can change
to the THR Curve D1 setting interface.
THR Curve D0
EPA: +100
EXP: 0
LEVEL
CUSTOM
1： 0.0
2：12.5
3：25.0
4：37.5
5：50.0
7：75.0
6：62.5
THR-D0
2. Roll the scroll wheel to select the setting item. Press and then roll the scroll
wheel to set the value of the item. After that, press the scroll wheel to save the
value.
