GAVIN-8C Instruction Manual
- 10 -
Specifications
2.4GHz, 8-channel receiver
larger than or equal to 4MHz
Features
Using ARM M3 processor, provides strong resolution capability.
Adopting 2.4GHz direct sequence spread spectrum (DSSS) and multiple
frequency-hopping spread spectrum (FHSS) technology, the receiver has
high sensitivity and strong anti-interference capability.
By using diversity antenna, can automatically switch the signals to ensure the
stability of the received signal.
Each transmitter has an individually assigned, unique ID code. Once the
binding is made, the ID code is stored in the receiver and no further binding is
necessary after restarting the receiver.
When the aircraft flies out of range, the receiver cannot receive a valid RF
signal from the transmitter and will move the servos to predefined position.
Support PPM and PWM signals.
Changing the Mode
According to the output signal types, RXC8 has a PPM mode and a PWM mode.
You can check the current mode from the mode LED on the receiver. After
powering on the receiver, the mode LED will stay red or green and will be off after
5 seconds. When the mode LED is off, you can light this LED by clicking the
Bind/Mode button.
Green: This indicates that the receiver works on PWM mode.
Red: This indicates that the receiver works on PPM mode.
You can change the receiver’s mode as needed. Changing the receiver from
