GAVIN-8C Instruction Manual
- 51 -
 Hidden: This timer is enabled, but does not display on the main screen.
 UP Timer: This timer is enabled, and displays on the main screen as up
timer.
 DOWN Timer: This timer is enabled, and displays on the main screen as
down timer.
The default is OFF.
3. Press UP or DOWN key to select Control SW, and then press R/+ or L/- key
to set the value (timer event).
Values:
 THR: The timer will be programmed to start when the throttle is raised
above a predefined position, and pause when falling below this position. If
the Control SW is set to THR, you need to set the THR Position. Values:
-100~100. The default is -90.
 SA: The timer will be programmed to start when you put the SA switch on
top or middle position, and pause when you put the SA switch on bottom
position.
 SD: The timer will be programmed to start when you put the SD switch on
top or middle position, and pause when you put the SD switch on bottom
position.
4. Press UP or DOWN key to select Timer (min) and (sec), and then press R/+
or L/- key to set the value.
Reset Model [Reset]
This function allows you to reset all the setting of current model or all models to
default values.
Setting Method:
1. In the Model Set menu, press UP or DOWN key to select Reset.
2. Press R/+ or L/- key to select to command, and then press ENT to execute
the command.
 Not Act: Keep the current setting, do not reset the model.
 Act: Reset the settings of current model to default values.
 All: Reset the settings of all models to default values.
