GAVIN-8C Instruction Manual
- 23 -
Delta Mix
1/5
1. Mix SW：
2.AIL AIL：
3.ELE AIL：
4.AIL ELE：
5.ELE ELE：
ON
100
100
-100
TxChs
100
........
AIL:0
ELE:0
THR:-100
RUD:0
GEAR:0
AUX1:0
AUX2:0
AUX3:0
3. Press UP or DOWN key to select the setting item, and then press R/+ or L/-
key to set the value of the item.
 AIL▶AIL: This parameter is used to set the mixing rate (percentage) from
aileron channel to itself. Values: -100~100. If the value is negative, it will
adjust the aileron operation in the negative direction. If the value is positive, it
will adjust the aileron operation in the positive direction. The default is 100.
 ELE▶AIL: This parameter is used to set the mixing rate (percentage) from
elevator channel to aileron channel. Values: -100~100. If the value is negative,
it will adjust the aileron operation in the negative direction. If the value is
positive, it will adjust the aileron operation in the positive direction. The default
is -100.
 AIL▶ELE: This parameter is used to set the mixing rate (percentage) from
aileron channel to elevator channel. Values: -100~100. If the value is negative,
it will adjust the elevator operation in the negative direction. If the value is
positive, it will adjust the elevator operation in the positive direction. The
default is 100.
 ELE▶ELE: This parameter is used to set the mixing rate (percentage) from
elevator channel to itself. Values: -100~100. If the value is negative, it will
adjust the elevator operation in the negative direction. If the value is positive,
it will adjust the elevator operation in the positive direction. The default is 100.
CAUTION: The delta mixing function cannot be utilized when either the V-tail
or Flaperon mixing function are active.
V-tail Mixing [V-tail Mix]
Corresponding model type: airplane, V-tail
