GAVIN-8C Instruction Manual
- 22 -
Mix Set
1/5
1. Delta Mix
2.V-tail Mix
3.Flaperon Mix
4.THR BAL Mix
5.Veer ELE Mix
OFF
OFF
OFF
Delta Mixing [Delta Mix]
Corresponding model type: airplane, delta wing
Delta (elevon) mixing mixes channel 1 (AIL) to channel 2 (ELE) allowing the
elevons to operate in unison (as elevators) or in opposition (as ailerons).
Setting Method:
1. In the Mix Set setting interface, press UP or DOWN key to select Delta Mix,
and then press ENT key to enter the setting interface.
Delta Mix
1/1
1. Mix SW：
OFF
TxChs
........
AIL:0
ELE:0
THR:-100
RUD:0
GEAR:0
AUX1:0
AUX2:0
AUX3:0
2. Modify the value of Mix SW to ON by pressing R/+ key, to activate the delta
mixing function.
The setting interface is shown in the following figure.
CH2
CH1
CH1 (AIL): aileron
CH2 (ELE): elevator
