GAVIN-8C Instruction Manual
- 20 -
2. Press UP or DOWN key to select the setting item, and then press R/+ or L/-
key to set the value of the item.
EPA: EPA (end point adjustment) is used to adjust the end point. The larger
the value is, the larger the servo travel is when move the stick. Values:
-100~100. The default is 100.
EXP: It is used to set the exponent of the curve. Offer a servo travel that is not
directly proportional to the stick travel. The control response is milder below
half-stick, but becomes increasing stronger as stick travel approaches 100%.
The larger the value is, the milder below half-stick. Values: 0~50. The default
is 0. When the value is set to 0, the servo travel is proportional to the stick
travel.
LEVEL: It is used to move up or down the curve.
CUSTOM/DEFAULT: When the value is CUSTOM, you can set the curve.
When the value is DEFAULT, the curve is switched to the default.
1~9: It is used to set the value of a specific point. The servo position can be
set independently for a maximum of 9 point positions. The screen can only
display 7 points at a time. You can scroll to select other setting points by
pressing UP or DOWN key.
Throttle Curve [THR Curve]
This function is used to adjust throttle servo operation in response to throttle stick
operation. The servo position can be set independently for a maximum of 9 point
positions.
Setting Method:
1. In the Airplane Parameter menu, press UP or DOWN key to select THR
Curve, and then press ENT key to enter the NORM THR Curve setting
interface.
NORM THR Curve
EPA: +100
EXP: 0
LEVEL
CUSTOM
1： 0.0
2： 12.5
3： 25.0
4： 37.5
5： 50.0
7： 75.0
6： 62.5
To Next Page
