1.6 Space requirements
1
1.6 Space requirements
To ensure that machine operation, consumables replacement and regular maintenance can easily be per-
formed, adhere to the recommended space requirements detailed below.
NOTICE
Be sure to allow a clearance of 200mm (8 inches) or more at the back of this machine.
570 (22-7/16)
ineo 164 Unit: mm (inch)
530 (20-7/8)
449 (17-11/16)
ineo 164 + MB-503 Unit: mm (inch)
928 (36-9/16)
449 (17-11/16)
783 (30-13/16)
607 (23-7/8)
570 (22-7/16)
856 (33-11/16)
927 (36-1/2)
