2.2 Main unit
2
2.2.2 Inside of the main unit
The illustration shows the main unit with an optional Multi Bypass Tray MB-503.
No. Name
1 Original Glass
2 Fusing Unit Top Cover
3 Fusing Unit
4 Drum
5 Paper Take-Up Roller
6 Toner Bottle
7 Original Scale
1
2
3
45
6
7
