Dexter Laundry A Series Service Procedures And Parts Data

Key Description T-300 T-400 T-600 T-900 T-1200 QTY
1 Panel Control Assembly(panel only) 9989-477-001 9989-478-001 9989-479-001 9989-480-001 9989-480-001 1
-- Screw, Hxwshrhdundct #10Bx 1/2” 9545-008-026 9545-008-026 9545-008-026 9545-008-026 9545-008-026 4
2 Post Locator Top 9467-024-001 9467-024-001 9467-024-001 2
-- Nut Hexkeps #6-32 8640-411-003 8640-411-003 8640-411-003 2
3 Locator Panel 9355-001-001 9355-001-001 9355-001-001 9355-001-001 9355-001-001 2
-- Screw FillHDCR 10Bx1/2” Guide 9545-008-025 9545-008-025 9545-008-025 9545-008-025 9545-008-025 2
-- Spacer Pushbutton (Micro) 9538-178-001 9538-178-001 9538-178-001 9538-178-001 9538-178-001 1
-- Retainer Pushbutton ( Micro) 9486-150-001 9486-150-001 9486-150-001 9486-150-001 9486-150-001 1
-- Nut Hexelasticstop #4-40 8640-424-002 8640-424-002 8640-424-002 8640-424-002 8640-424-002 2
10 Pushbutton Control (Micro) 9035-060-002 9035-060-002 9035-060-002 9035-060-002 9035-060-002 1
7 PCB assembly Control /Display 9473-004-001 9473-004-001 9473-004-001 9473-004-001 9473-004-001 1
11 Spacer Plastic #6x9/16 9538-157-018 9538-157-018 9538-157-018 9538-157-018 9538-157-018 5
11 Nut Elasticstop #6-32 8640-411-002 8640-411-002 8640-411-002 8640-411-002 8640-411-002 5
-- Harness LEDPCB 9627-797-001 9627-797-001 9627-797-001 9627-797-001 9627-797-001 1
8 Harness Doorlock 9627-791-003 9627-791-003 9627-791-004 9627-791-004 9627-791-004 1
16 PCB assembly Mode lights 9473-005-001 9473-005-001 9473-005-001 9473-005-001 9473-005-001 1
-- Spacer Plastic #6x9/16 9538-157-018 9538-157-018 9538-157-018 9538-157-018 9538-157-018 2
9 Nut Hexkeps #6-32 8640-411-003 8640-411-003 8640-411-003 8640-411-003 8640-411-003 2
19 Light, LED,ADD BLEACH Assembly 9794-001-001 9794-001-001 9794-001-001 9794-001-001 9794-001-001 1
-- Spacer Plastic #6x9/16 9538-157-018 9538-157-018 9538-157-018 9538-157-018 9538-157-018 2
-- Nut Hexeps #6-32 8640-411-003 8640-411-003 8640-411-003 8640-411-003 8640-411-003 2
-- Nameplate,Control Panel (one piece) 9412-117-001 9412-118-001 9412-116-001 9412-119-001 9412-134-001 1
-- Spacer Plastic #8x5/16 E-Stop 9538-157-020 9538-157-020 9538-157-020 9538-157-020 9538-157-020 2
-- Nut HexKep #8-32 E-Stop 8640-412-005 8640-412-005 8640-412-005 8640-412-005 8640-412-005 2
-- Solenoid Ass’y, Door Locking 9922-011-001 9922-011-001 9922-011-001 9922-011-001 9922-011-001 1
(see Door Lock Group for
parts breakdown )
-- Hex Nuts 8640-412-005 8640-412-005 8640-412-005 8640-412-005 8640-412-005 3
(mounting solenoid assy.
to control panel )
26 Battery 8612-001-001 8612-001-001 8612-001-001 8612-001-001 8612-001-001 1
125 Lock-Run Program w/ Harness 8650-027-001 8650-027-001 8650-027-001 8650-027-001 1
-- Plastic Shield over main PCB 9550-184-001 9550-184-001 9550-184-001 9550-184-001 9550-184-001 1
-- PCB Optional Relay 9473-008-001 9473-008-001 9473-008-001 9473-008-001 9473-008-001 1
Parts Data
101
Control Panel Part # by Model
