Key Description T-300 T-400 T-600 T-900 T-1200 QTY

-- Wiring Harness 9794-001-001 9794-001-001 9794-001-001 9794-001-001 9794-001-001 1

( Add Bleach Lite assy included )

-- Wiring Harness, Door Lock 9627-791-003 9627-791-003 9627-791-004 9627-791-004 9627-791-004 1

-- Wiring Harness P23/P15 9627-798-001 9627-798-001 9627-798-001 9627-798-001 9627-798-001 1

-- Wiring Harness, Drain,Thermo,DoorSol 9627-796-001 9627-796-001 9627-796-002 9627-796-002 9627-796-002 1

-- Data Cable 9806-015-001 9806-015-001 9806-015-001 9806-015-001 9806-015-003 1

-- Wiring Harness P20/P21 9627-793-001 9627-793-001 9627-793-001 9627-793-001 9627-793-001 1

-- Wiring Harness P8/P16 9627-794-001 9627-794-001 9627-794-001 9627-794-001 9627-794-001 1

-- Wiring Harness WaterValve/P19 9627-795-001 9627-795-001 9627-795-002 9627-795-002 9627-795-002 1

-- Wiring Harness LED PCB 9627-797-001 9627-797-001 9627-797-001 9627-797-001 9627-797-001 1

-- Wiring Harness P5/pressure 9627-800-001 9627-805-001 9627-806-001 9627-807-001 9627-807-001 1

-- Wiring Assembly Yel. 32” 8220-064-023 8220-064-023 8220-064-023 8220-064-023 2

-- Wiring Assembly Yel. 64” 8220-064-040 2

-- Wiring Assembly Red 20” 8220-001-282 8220-001-282 2

-- Wiring Assembly Red 41” 8220-062-032 2

-- Wiring Assembly Vio. 24” 8220-118-001 8220-118-001 8220-118-001 2

-- Wiring Assembly Wht/Brn 8” 8220-108-007 1

-- Wiring Assembly Jumper Yel 8220-123-001 8220-123-001 8220-123-001 8220-123-001 8220-128-001 1

-- Wiring Assembly Red 28” 8220-062-025 8220-062-025 2

-- Wiring Assembly Blk. 17” 8220-062-028 8220-062-028 8220-062-028 8220-062-028 8220-062-028 1

-- Wiring Assembly Red 17” 8220-062-027 8220-062-027 8220-062-027 8220-062-027 8220-062-027 1

-- Wiring Assembly Jumper BLK. 8220-117-001 8220-117-001 8220-117-002 8220-117-003 2

-- Wiring Assembly Red 7” 9631-381-018 9631-381-018 9631-381-018 9631-381-018 9631-381-018 1

-- Wiring Assembly Blu/Wht 8220-090-009 8220-090-009 8220-090-009 8220-090-009 8220-090-009 1

-- Wiring Assembly Blk/Blu 8220-001-231 8220-001-231 8220-001-231 8220-001-231 8220-001-231 1

-- Wire Assembly Green 7” 8220-001-478 1

-- Harness Power Terminal Block 9627-831-001 9627-747-003 9627-747-003 9627-747-002 9627-747-002 1

-- Wire Assembly Blk/Red 1/2” 8220-001-465 8220-001-465 8220-001-465 8220-001-465 1

-- Wire Harness P-10 9627-799-001 9627-799-001 9627-799-001 9627-799-001 9627-799-001 1

-- Lock Run Program Switch w/ harness 8650-027-001 8650-027-001 8650-027-001 8650-27-001 8650-027-001 1

Parts Data

96

Wiring Harness Part # by Model

Dexter Laundry A Series Service Procedures And Parts Data
