Dexter Laundry A Series Service Procedures And Parts Data

Parts Data
82
Cabinet and Front Panel Group Part # by Model
Key Description T-300 T-400 T-600 T-900 T-1200 QTY
1 Panel, Side (Left or Right) - stainless 9454-656-001 9989-449-001 2
1 Panel, Side (Left or Right) - stainless 9454-672-001 9454-760-001 4
1 Panel, Right Side-stainless 9454-635-005 1
1 Panel, Left Side - stainless 9454-635-006 1
2 Screw, (Side Panel to Base) 9545-018-018 9545-018-013 6
2 Screw, (Side Panel to Base) 9545-018-013 9545-018-013 9545-018-013 8
2 Nut, Hex 1/4-20 UNC 8640-414-006 8640-414-006 6
2 Nut, Hex 1/4-20 UNC 8640-414-006 8640-414-006 8640-414-006 8
3 Bracket, Side Panel 9029-066-001 9029-066-001 9029-066-001 1
under front panel
• Nut, Hex 8640-413-002 8640-413-002 8640-413-002 2
* Screw 9545-008-031 9545-008-024 9545-008-024 2
4 Panel Assy, Front 9454-728-002 9454-659-002 9454-669-003 9454-671-003 9454-768-001 1
* Risk of Injury Label 8502-722-002 8502-722-002 8502-722-002 8502-722-002 8502-722-001 1
5 Band, Edge Protector 9059-063-004 9059-063-002 9059-063-002 9059-063-002 9059-063-002 1
* Bumper Loading Door 9051-053-001 1
* Screw, Hex- To Control Panel 9545-008-031 9545-008-024 9545-008-024 9545-008-024 9545-008-024 2
* Nut, Spring- To Control Panel 10/32 8640-399-005 8640-399-005 8640-399-005 8640-399-005 8640-399-005 2
6 Screw, Flat Head- Front to Sides 9545-008-014 9545-008-014 9545-008-014 9545-008-014 9545-008-014 2
6 Washer, Finish 8641-585-001 8641-585-001 8641-585-001 8641-585-001 8641-585-001 2
* Nut, Spring-To Front Panel 8640-399-008 8640-399-008 8640-399-008 8640-399-008 8640-399-008 2
7 Label, Door Opening 8502-723-001 8502-723-001 8502-723-001 8502-723-001 8502-723-001 2
8 Panel, Control (Mounts Nameplate) 9989-477-001 9989-478-001 9989-479-001 9989-480-001 9989-480-001 1
* Screw, Control Panel to Sides 9545-008-026 9545-008-026 9545-008-026 9545-008-026 9545-008-026 4
9 Nameplate Decal, Control Panel 9412-117-001 9412-118-001 9412-116-001 9412-119-001 9412-134-001 1
10 Panel Top 9989-498-001 9454-734-001 9454-735-001 9454-736-001 1
10 Panel Top Front 9454-761-001 1
10 Panel Top Rear 9454-762-001 1
11 Lock, Top (w/Key) 8650-012-003 8650-012-003 8650-012-003 1
11 Lock, Top (w/Key) 8650-012-003 8650-012-003 2
19 Key, Top- # 6324 6292-006-007 6292-006-007 6292-006-007 6292-006-007 6292-006-007 1
19 Cam, Lock-Top 9095-038-001 9095-038-001 9095-038-001 9095-038-001 9095-038-001 1
-- Nut, 9/32 - 28 Hex 8640-426-001 8640-426-001 8640-426-001 8640-426-001 8640-426-001 1
-- Washer Flat 5/16 8641-581-008 8641-581-008 8641-581-008 8641-581-008 8641-581-008 1
-- Catch, Top Panel 9086-017-001 9086-017-001 9086-017-001 2
16 Screw, Guide 9545-008-023 9545-008-023 9545-008-023 2
12 Door, Lower Service 9108-096-001 9108-097-001 9108-097-001 9108-099-001 9108-099-001 1
13 Handle (bumper guard) 9244-081-001 9244-081-002 9244-081-002 9244-081-003 9244-081-003 1
* Screw 9545-045-010 9545-045-010 9545-045-010 9545-045-010 9545-045-010 4
14 Screw Mtg., Flat Head 9545-008-014 9545-008-014 9545-008-014 9545-008-014 9545-008-014 2
14 Washer, Finish 8641-585-001 8641-585-001 8641-585-001 8641-585-001 8641-585-001 2
