Dexter Laundry A Series Service Procedures And Parts Data

Parts Data
84
Rear View Access Part # by Model
Key Description T-300 T-400 T-600 T-900 T-1200 QTY
1 Drive Motor, 3 Phase (Inverter duty) 9732-127-011 9732-127-012 9732-127-012 9376-308-001 9376-298-001 1
Drive Motor After Serial #483620 9732-225-001
2 Rod, Motor Mtg 9497-222-002 9497-222-002 9497-222-004 1
-- Screw (end of motor rod) 9545-029-005 9545-029-005 9545-029-005 1
-- Lockwasher (end of motor rod) 8641-582-014 8641-582-014 8641-582-014 1
3 Collar, Shaft (w/set screws) 9076-052-002 9076-052-002 9076-052-002 9076-052-002 9076-052-002 2
4 Pulley, Motor 9453-169-012 9453-170-003 9453-170-003 9453-175-002 9453-175-002 1
-- Set Screw,Sq.Hd(motor pulley) 9545-028-015 9545-028-015 9545-028-015 2
-- Tolerance Ring 9487-234-002 9487-234-001 9487-234-003 1
5 Pulley, Driven 9908-041-002 9453-168-004 9453-168-003 9453-176-005 9453-176-005 1
6 Screw 1/2-13x1 1/4” 9545-017-009 9545-017-009 1
6 Screw 5/8-11x1/1/2” 9545-060-001 1
6 Lockwasher 1/2” 8641-582-016 8641-582-016 1
6 Lockwasher 5/8” 8641-582-018 1
7 Washer, Flat 1/2” 8641-581-026 8641-581-026 1
7 Washer, Flat 5/8x2 1/4” 8641-581-032 1
8 Drive Belt 9040-076-004 9040-079-002 9040-079-003 1
8 Drive Belt 9040-076-005 9040-076-005 2
9 Channel, Rear 9081-132-001 9081-135-001 9081-134-001 9081-109-001 9081-140-001 1
10 Screw 9545-008-026 9545-008-026 9545-008-026 9545-008-026 9545-008-026 4
-- Nut, Spring 8640-399-008 8640-399-008 8640-399-008 4
-- Nut, Spring 8640-399-008 8640-399-008 6
-- Nut, Spring 8640-399-004 8640-399-004 8640-399-008 6
11 Hose, Overfl ow to drain 9242-449-002 9242-449-002 9242-449-002 9242-449-003 9242-449-003 1
-- Hose, Overfl ow Vent Top 9242-463-001 9242-463-001
12 Clamp, Hose Vent 8654-117-008 8654-117-008 8654-117-008 8654-117-008 8654-117-008 2
12 Clamp, Hose overfl ow to drain 8654-117-018 8654-117-018 8654-117-018 8654-117-018 8654-117-018 2
13 Vaccum Breaker ALL 9610-001-001 9610-001-001 9610-001-001 9610-001-001 9610-001-001 1
-- Clamp, Hose to Vacuum Breaker 8654-117-014 8654-117-014 8654-117-014 8654-117-014 8654-117-014 1
16 Inlet Hose 9242-458-001
14 Plastic Plug 7/8” Electrical Connection 9456-041-006 9456-041-006 9456-041-006 2
-- Panel Assy., Back 9454-632-001 9989-446-002 9989-446-001 9989-455-001 9989-491-001 1
-- Screw Panel Mtg.#10Bx1/2” 9545-008-026 9545-008-026 9545-008-026 10
-- Screw Panel Mtg.#10Bx1/2” 9545-008-026 9
-- Screw, 10Bx 1/2 Panel Mtg 9545-008-026 13
15 Hose, Pressure Switch 9242-175-000 9242-175-000 9242-175-002 9242-175-007 9242-175-006 1
-- Clamp, Pressure Switch Hose 8654-117-015 8654-117-015 8654-117-015 8654-117-015 8654-117-015 1
29 Bushing Taperlock (Driven & Large) 9053-078-002 9053-078-002 1
30 Bushing, Split Taper (Motor Pulley) 9053-077-001 9053-077-001 1
-- Screw For Split Taper (1/4 - 20 x1) 9545-018-024 9545-018-021 3
-- Screw, To Base-1/4x3/4 9545-030-002 9545-030-002 1
18 Strap Bracket, Motor Tension 9029-027-003 9029-027-003 9029-027-003 1
-- Cover Injection Terminal 9074-296-001 9074-296-001 9074-296-001 9074-296-001 9074-296-001 1
