Dexter Laundry A Series Service Procedures And Parts Data

Parts Data
99
Chassis and Drain Part # by Model (continued)
Key Description T-300 T-400 T-600 T-900 T-1200 QTY
-- Washer 8641-582-016 1
-- Nut 1/2” 8640-417-005 4
-- Hose, Tub to Drain Valve 9242-455-001 9242-456-001 9242-456-001
9242-459-001 9242-459-001 1
8 Lockwasher 8641-582-018 8641-582-018 4
8 Nut, Hex 5/8-11 8640-425-001 8640-425-001 4
9 Valve, Drain 9379-177-009 9379-187-004 9379-187-004 9379-187-004 9379-187-004 1
10 Bracket, Drain Valve 9029-005-001 9029-005-001 9029-055-001 1
-- Screw, Valve to Bracket 12ABx1/2 9545-008-026 9545-008-026 9545-030-020 1
19 Hose, Drain Valve to Tube 9242-451-002 9242-457-001 9242-457-001
9242-457-001 9242-457-001 1
-- Clamp, Hose (Drain Valve to Tube) 8654-117-014 8654-117-014 8654-117-014 4
-- Clamp, Hose (Drain Valve to Tube)
8654-117-014 8654-117-014 5
-- Shim, Support Assembly ( thin ) 9552-038-003 9552-038-001 9552-038-003
9552-013-003 9552-013-003 AR
18 Hose, Vacuum Brkr. to Tub 9242-458-001 1
13 Dispenser Soap 9122-105-004 9122-105-004 9122-105-004 9122-105-004
1
15 Gasket, Dispenser 9206-416-001 9206-416-001 9206-416-001
9206-416-001 1
-- Nut Spring SS 8640-399-007 8640-399-007 8640-399-007 8640-399-007 4
-- Hose, Dispenser to Tub 9242-450-002 9242-450-002 9242-450-001
9242-450-001 1
-- Clamp, Dispenser Hose 8654-117-008 8654-117-008 8654-117-008
8654-117-008 8654-117-008 2
14 Back Ass’y, Tub 9732-137-001 9732-137-002 9732-137-003 1
16 Bolt, 7/16” x 2” Tub Back to Tub 9545-029-003 9545-029-002 9545-029-003 12
17 Nut, Flange Lock 8640-415-004 8640-416-005 8640-416-005 12
20
Bolt, 1/2-13x2, Grd 5 Tub to Base 9545-017-013 9545-017-013 2
--
Washer, Flat 8641-581-026 8641-581-026 4
21 Soap Box Assembly Complete SS 9807-091-001 1
-- Soap Box mounting Gasket 9206-425-001 1
22 Lid Assembly soap box 9987-104-001 1
-- Lid screws #10-32x1/2 SS 9545-012-017 1
-- Screw Hexhead 1/2 x 2 9545-017-013 9545-017-013 1
-- Nut Whizlok 8640-417-005 1
-- Nut Hex Elasticstop #10-32 SS 8640-413-006 6
-- Spacer Plastic #10x1/2 9538-157-019 4
-- Bracket Soap box mounting 9029-148-001 1
23 Softener siphon tube 9574-252-002 1
-- Flow restictors 9475-002-003 3
25 Front Ass’y, Tub 9974-007-001 9974-007-002 1
-- Screw, 3/8-16x3 9545-029-009 9545-029-009 1
24 Nut, Hex 3/8-16 8640-415-001 8640-415-001 1
-- Gasket, Tub Front 9206-421-002 9206-421-002 1
-- Pipe Plug 1/2” 8615-104-039 8615-104-039 2
