NUMBER
Bolt Size Where Used Torque BOLTS REQ.
1/2” bolt Tub End of Bearing Housing 70-110 ft/lbs
9545-017-009 GRADE #5 6
1/2” bolt Mounting of Tub to Cradle Assembly 70-110 ft/lbs
9545-017-009 GRADE #5 4
3/8” bolt Tub Back Ring to Tub Back 45-80 ft/lb
9545-029-003 GRADE#8 12
3/8” bolt Pulley End of Bearing Housing 45-80 ft/lbs
9545-029-003 GRADE #8 6
3/8” bolt Mounting ring ends (front ) 20-30 ft/lbs
9545-029-003 GRADE #8 1
Basket Pulley to Shaft(set screw) 190-200 in/lbs
9545-028-015 SQUARE HD. SET SCREW 1
T-300 Bolt Torque Chart
Machine Service Procedures
54
Bolt Size Where Used Torque
7/16” Stainless Cap Screw Outer Tub to Bearing Housing 60-80 ft/lbs
3/4” Bolt Bearing Housing to Frame 200-300 ft/lbs
1/2” Bolt Outer Tub Clamping Band to Frame 70-110 ft/lbs
1/2” Bolt Outer Tub Clamping Band - Top 30-40 ft/lbs
3/8” Cap Bolt Drive Pulley to Hub 30 ft/lbs
T-900 & T-1200 Bolt Torque Chart
Bolt Size Where Used Part Number Torque
1/2”x 1 1/4” bolt Tub End of Bearing Hsing. 9545-017-009 70-110 ft/lbs
5/8”x 1 1/2” bolt Tub End of Bearing Hsing. 9545-060-001 120-150 ft/lbs
1/2”x 1 1/4” bolt Mtg. of Tub to Cradle Asy. 9545-017-009 70-110 ft/lbs
5/8”x 2 1/2”bolt Mtg. of Tub to Cradle Asy. 9545-060-001 120-150 ft/lbs
3/8”x 1 1/2” bolt Tub Back Ring to Tub Back 9545-029-003 45-80 ft/lbs
T-400 & T-600 Bolt Torque Chart
