Key Description T-300 T-400 T-600 T-900 T-1200 QTY

1 Valve, Water Inlet (dual outlet) 9379-192-001 9379-192-001 9379-192-001 9379-192-001 9379-192-001 2

(see Water Inlet Valve Breakdown

for individual parts)

2 Valve Water Inlet (single outlet) 9379-194-001 2

-- Screw, Valve Mtg 9545-008-026 9545-008-026 9545-008-026 9545-008-026 4

-- Nut, Spring 8640-399-009 8640-399-009 8640-399-009 8640-399-009 4

-- Screw, Valve M4x0.7x8mm 9545-064-001 8

-- Guard Water Valve Terminal 9208-049-001 9208-049-001 1

4 Vacuum Breaker 9610-001-001 9610-001-001 9610-001-001 9610-001-001 9610-001-001 1

-- Bracket, Vacuum Breaker 9029-065-001 9029-065-001 9029-077-001 9029-069-001 9029-069-001 1

-- Screw 9545-008-026 9545-008-026 9545-008-026 9545-008-026 9545-008-026 4

-- Shield over Water Valves Plastic 9550-186-001 9550-186-001 9550-186-001 9550-186-001 1

-- Clamp, Vacuum Breaker End 8654-117-014 8654-117-014 8654-117-014 8654-117-014 8654-117-014 1

-- Clamp, Tub End 8654-117-009 8654-117-009 8654-117-009 1

6 Hose, Vac. Brkr. to Disp.29” 9242-453-015 9242-453-016 9242-043-008 9242-453-018 1

7 Hose, Vac. Brkr. to Disp.26” 9242-453-016 9242-453-017 9242-043-009 9242-453-019 1

8 Hose, Hot Valve to Vac. Brkr 18” 9242-453-020 9242-453-020 9242-453-020 9242-453-020 1

9 Hose, Hot Valve to Tub 18” 9242-453-020 9242-453-020 9242-453-020 9242-453-020 1

10 Hose, Cold Valve to Vac. Brkr 18” 9242-453-020 9242-453-020 9242-453-020 9242-453-020 1

11 Hose, Cold Valve to Tub 18” 9242-453-020 9242-453-020 9242-453-020 9242-453-020 1

12 Hose, Vac. Brkr. dispenser 43” 9242-453-022 3

13 Hose, (valve to vac. Brkr) 23” 9242-453-009 4

-- Clamp, Hose-Spring 8654-117-018 8654-117-018 8654-117-018 8654-117-018 8654-117-018 2

( overﬂ ow from drain to tub back )

-- Clamp, Hose-Worm 8654-117-015 8654-117-015 8654-117-015 8654-117-015 8654-117-015 1

-- Flow restrictor 9475-002-002 9475-002-002 9475-002-002 9475-002-002 2

-- Flow restrictor 9475-002-003 3

-- Circuit Breaker (optional) 5198-211-004 5198-211-004 5198-211-004 5198-211-004 1

14 Fuseholder 9200-001-002 9200-001-002 9200-001-002 9200-001-002 9200-001-002 1

15 Fuse 1.5 amp 8636-018-001 8636-018-001 8636-018-001 8636-018-001 1

15 Fuse 2.5 amp 8636-018-004 1

16 Injector Assembly 9883-006-001 9883-007-001 9883-005-001 9885-005-001 1

17 Injector Assembly Cap 0935-127-001 0935-127-001 0935-127-001 0935-127-001 1

18 Injector Hose 9242-461-001 9242-461-001 9242-461-001 9242-461-001 1

19 Injector Hose 2” Diameter 9242-462-001 9242-462-001 9242-461-001 9242-461-001 1

20 Clamp 8654-117-008 8654-117-014 8654-117-014 8654-117-014 2

-- Clamp 8654-117-009 8654-117-009 8654-117-014 8654-117-014 2

Parts Data

93

Water Inlet Part # by Model
