Table of Contents
WARNING
THESE WASHERS ARE EQUIPPED WITH DEVICES AND
FEATURES RELATING TO THEIR SAFE OPERATION. TO
AVOID INJURY OR ELECTRICAL SHOCK, DO NOT PERFORM
AND SERVICE, UNLESS QUALIFIED TO DO SO.
A machine should not be allowed to operated if any of
the following occur:
- Excessively high water level.
- Machine is not connected to a properly
grounded circuit.
- Loading door does not remain securely locked
during the entire cycle.
- Vibration or shaking from an inadequate
mounting or foundation.
WARNING - FOR SAFETY
1. Always shut off power and water supply and also
discharge capacitors before servicing.
2. Do not overload the washer.
3. Do not attempt to open door if cylinder is in motion
or contains water.
4. Do not mechanically force or override door lock in
any way.
5. Do not bypass any safety devices of this washer.
6. Do not use volatile or fl ammable substances in or
near this washer.
7. Keep all panels in place. They protect against shock
and injury and add rigidity to the washer.
Dexter Safety Guidelines
2
To activate your warranty--be sure to
return your red warranty form to the
factory. Please have serial # and model
ready when calling for assistance.
Section 1:
Machine Mounting
& Installation
T-300.........................................6
T-400 & T-600............................7
T-900 & T-1200..........................8
T-300 Installation.......................9
T-400 Installation.....................10
T-600 Installation......................11
T-900 Installation.....................12
T-1200 Installation...................13
Section 2:
Machine Installation
& Operating Instructions
Basic Installation and
Operation............................15-17
Electrical Connections, Fusing
Requirements & Liquid Chemical
Connections.............................18
Machine Operating
Instructions..............................19
Section 3:
Machine Programming
Instructions
Programming
Instructions......................22 & 23
Washer Cycle Parameter
Ranges....................................24
Rapid Advance Mode...............27
Injection Source Details...........27
Section 4:
Trouble Shooting
Common Troubleshooting
Solutions Pages..................30-34
Troubleshooting Machine
Fault Errors Pages.............35-39
Variable Frequency Drive Control
Digital Readout Faults.............40

Table of Contents
