Dexter Laundry A Series Service Procedures And Parts Data

Key Description T-300 T-400 T-600 T-900 T-1200 QTY
* Housing, Bearing- Assembly (items #2-#6) 9803-182-001 9803-179-002 9803-186-001 9803-187-001 9803-187-001 1
2 Housing, Bearing 9241-174-002 9241-169-002 9241-180-002 9241-181-004 9241-181-004 1
3 Bearing, Front ( LARGE ) 9036-159-001 9036-159-002 9036-159-005 9036-159-006 9036-159-006 1
4 Bearing, Rear ( SMALL ) 9036-159-003 9036-159-001 9036-159-004 9036-159-005 9036-159-005 1
5 Spacer, Bearing 9538-161-001 9538-158-001 9538-167-001 9538-170-001 9538-170-001 1
6 Ring, Bearing Retainer 9487-238-002 9487-238-001 9487-238-003 9487-238-004 9487-238-004 1
7 Back Assy, Tub 2 piece 9732-137-001 9732-137-002 9732-137-003 1
8 Seal, Primary 9532-140-004 9532-140-009 9532-140-009 9532-140-008 9532-140-008 1
9 Seal, Secondary 9532-140-005 9532-140-003 9532-140-006 9532-140-007 9532-140-007 1
10 Ring, Seal Mounting 9950-047-001 9950-042-001 9950-048-001 9950-052-001 9950-052-001 1
11 Tub Back Mating Ring 9487-261-001 9487-261-002 9487-261-003 9487-261-004 9487-261-004 1
11G Mating Ring Guard Shield 9487-266-001 9487-266-001 1
12 Bolt, Tub End of Bearing Housing 9545-017-009 9545-017-009 6
( 1/2” x 1 1/4” )
12 Nut 1/2’ 8640-417-002 8640-417-005 6
12 Lockwasher 1/2” ( ext. tooth) 8641-582-016
12 Bolt 5/8-11x1 1/2” Tub end of 9545-029-003 9545-059-003 6
bearing housing
12 Nut 5/8” 8640-425-001 6
12 Lockwasher 5/8” 8641-582-018 6
13 Support Arm Assy, Bearing Housing 9991-049-002 9991-048-002 9991-056-002 6
14 Bolt Pulley End of Bearing Housing 9545-029-003 6
( 3/8” x 1 1/2” )
14 Nut, Flange Locking 3/8” 8640-415-004 6
14 Bolt Pulley end of bearing housing 9545-059-003 6
( 7/16-14x2” )
14 Nut, Flange Locking 7/16” 8640-416-005 6
15 Pulley, Driven 9908-041-002 9453-168-004 9453-168-003 9453-176-005 9453-176-005 1
-- Ring, Tolerance 9487-234-002 9487-234-001 9487-234-003 1
16 Washer 1/2” 8641-581-026 8641-581-026 1
16 Washer 5/8” 8641-581-032 1
18 Bolt 1/2-13 x 1 1/4” 9545-017-009 9545-017-009 1
19 Bolt 5/8-11x11/2” 9545-060-001 1
20 Lockwasher 1/2” Ext. tooth 8641-582-016 8641-582-016 1
18 Lockwasher 5/8 Ext. tooth 8641-582-018 1
-- Cylinder Assy 9848-111-001 9848-109-001 9848-113-001 9848-116-001 9848-125-001 1
-- Tub and Cylinder Assy. 9869-006-001 9869-016-001 9869-017-001 9869-018-001 9869-015-002 1
21 Screw, Bearing Housing, 3/4-10 x 3 9545-057-002 9545-057-002 6
-- Washer, Flat- To Frame 8641-581-033 6
-- Washer, External Tooth 8641-582-020 6
-- Nut 3/4-10 8640-418-003 8640-418-003 6
-- Screw, 7/16-14 x 1 SS 9545-059-004 9545-059-004 6
(Tub Back to Bearing Housing)
-- Flat Washer 8641-582-020 6
Parts Data
86
Cylinder, Seals & Bearings Part # by Model
