Fault# Description Customer Action
Variable Frequency Drive Control Digital Readout Faults
CE1
VFD received an illegal command.
Possible controller problem
CE2
CE3
CE4
CE6
Illegal data address, VFD received
an address not available to the
controller.
Illegal data value received at VFD.
Possible controller problem.
VFD unable to perform the requested
action. Possible controller problem.
Time frame between commands is to
short. Possible controller problem.
CE9
Internal checksum error. VFD problem.
CE10
Watch dog timer. Command not
received from the controller every 6
seconds
CE11
Frame error. Possible Baud rate issues
between VFD and controller
CE12
Command message is to short.
Possible controller problem
CE13
Command message is to long.
Possible controller problem
CE14
Command message includes
unused characters. Possible
controller problem.
Normal operation of the VFD: VFD display shows operating frequency fi rst very quickly then changes to F0.0 at
time power is returned. This will stay displayed until the VFD receives a command from main control PCB.
(Pushing start button) A CE-10 fault will display at drive if improper communication between PCB and VFD has
occurred. Note: Resetting a fault code on front of washer: Turn the power off to machine (machine will need to
remain off for up to three minutes ).
SOFT RESET : is accomplished by pushing the white button located on the Main controller PCB board and
simultaneously turning power on to machine. This will reset main controller to factory default settings.
Please record any modifi ed information that has been inserted in memory before attempting to Soft Reset the PCB.
CE5, CE7 and CE8—Reserved by DELTA
40
Soft reset drive.
Soft reset drive.
Soft reset drive.
Soft reset drive.
Soft reset drive.
Soft reset drive.
Soft reset drive.
Soft reset drive.
Soft reset drive.
Soft reset drive.
Soft reset drive.
