Dexter Laundry A Series Service Procedures And Parts Data

Parts Data
91
Loading Door Part # by Model
Key Description T-300 T-400 T-600 T-900 T-1200 QTY
-- Loading Door, Complete #1-10 9960-273-001 9960-274-002 9960-274-004 9960-274-004 9960-274-004 1
1 Loading Door, Ring 9487-264-001 9487-265-001 9487-265-002 9487-265-002 9487-265-002 1
2 Gasket, Loading Door 9206-411-002 9206-419-001 9206-419-001 9206-419-001 9206-419-001 1
3 Window, Loading Door 9635-018-001 9635-016-001 9635-016-001 9635-016-001 9635-016-001 1
-- Shaft Assy, Locking (includes 4 thru 7) 9913-134-003 9913-134-003 9913-134-003 9913-134-003 9913-134-003 1
4 Shaft, Door Locking 9537-195-002 9537-195-002 9537-195-002 9537-195-002 9537-195-002 1
5 Cam, Locking 9095-040-002 9095-040-002 9095-040-002 9095-040-002 9095-040-002 1
6 Pin, Groove (1 1/4) 9451-181-005 9451-181-005 9451-181-005 9451-181-005 9451-181-005 1
7 Pin, Groove (3/4) 9451-181-004 9451-181-004 9451-181-004 9451-181-004 9451-181-005 1
8 Spring, Lock Cam 9534-360-002 9534-360-002 9534-360-002 9534-360-002 9534-360-002 1
9 Handle, Door 9244-080-003 9244-080-003 9244-080-003 9244-080-003 9244-080-003 1
10 Door Hinge Assy (mounts to Tub Front) 9243-079-001 9243-079-001 9955-030-001 9955-030-001 9955-030-001 1
20 Pin, Door Handle (groove) 9451-181-006 9451-181-006 9451-181-006 9451-181-006 9451-181-006 1
21 Screw, Hinge Mtg 5/16” x 3/4” 9545-014-009 9545-014-009 9545-014-009 9545-014-009 9545-014-009 3
-- Lockwasher 5/16” Ext tooth 8641-582-009 8641-582-009 8641-582-009 8641-582-009 8641-582-009 3
-- Shim, Loading Door Hinge, Thin 9552-036-001 9552-036-001 9552-036-001 9552-036-001 9552-036-001 AR
11 Loading Door Hinge Pin Brass 9451-184-004 9451-184-004 1
-- Ring, Retaining ( snap ring ext ) 8649-031-000 8649-031-000 1
12 Loading Door Hinge Clamp 9938-040-001 9938-040-002 1
(mounts to door ring )
13 Screw, Loading Door Mtg (5/16” TF) 9545-056-002 9545-056-002 9545-056-002 9545-056-002 3
14 Masking Assembly 9950-059-001 9950-060-001 9950-060-002 9950-060-002 9950-060-002 1
-- Rubber Edge (mounts to Front Panel ) 9059-063-004 9059-063-002 9059-063-002 9059-063-002 9059-063-002 1
-- Nut, Keps 8640-413-002 8640-413-002 8640-413-002 8640-413-002 8640-413-002 4
15 Switch Safety 9539-461-007 9539-461-007 9539-461-007 9539-461-007 9539-461-007 1
16 Safety switch shield 9550-159-001 9550-159-001 9550-159-001 9550-159-001 9550-159-001 1
-- Wiring Harness doorlock safety switch 9627-791-003 9627-791-003 9627-791-004 9627-791-004 9627-791-004 1
17 Wires Red 8220-062-027 8220-062-027 8220-062-027 8220-062-027 8220-062-027 1
18 Wires Black 8220-062-028 8220-062-028 8220-062-028 8220-062-028 8220-062-028 1
19 Switch Assembly Complete 9801-089-001 9801-089-001 9801-089-001 9801-089-001 9801-089-001 1
Door Closure
22 Switch Box 9041-087-001 9041-087-001 9041-087-001 9041-087-001 9041-087-001 1
-- Bushing Insulating 9053-067-003 9053-067-003 9053-067-003 9053-067-003 9053-067-003 1
-- Nut Special Twin #4-40 8640-401-001 8640-401-001 8640-401-001 8640-401-001 8640-401-001 1
-- Screw 4-40x5/8 9545-020-001 9545-020-001 9545-020-001 9545-020-001 9545-020-001 2
-- Door Switch Actuator 9008-004-001 9008-004-001 9008-004-001 9008-004-001 9008-004-001 1
23 Top, Loading Door Leaf Hinge.with pin 9845-005-003 9845-005-003 1
24 Bottom, Loading Door Leaf Hinge 9845-005-002 9845-005-002 1
25 Screw, Loading Door Mtg. 9845-056-002 9545-056-002 1
