Dexter Laundry A Series Service Procedures And Parts Data

83
Key Description T-300 T-400 T-600 T-900 T-1200 QTY
* Nut, Spring 8640-399-008 8640-399-008 8640-399-008 8640-399-008 8640-399-008 2
15 Door, Dispenser 9108-095-005 9108-095-005 9108-095-005 9108-095-005 9987-104-001 1
20 Pin, Plain 9451-191-001 9451-191-001 9451-191-001 9451-191-001 2
21 Post, Door Mounting 9467-025-001 9467-025-001 9467-025-001 9467-025-001 2
22 Screw, Disp.Post Mtg 9545-045-002 9545-045-002 9545-045-002 9545-045-002 4
23 Screw, Disp. Mtg 9545-008-012 9545-008-012 9545-008-012 9545-008-012 1
18 Plastic Plug 1 1/2”-(inside cylinder) 9456-041-007 9456-041-007 9456-041-007 1
Soap Box Gasket Box Mount 9206-425-001
Soap Box Assembly 9807-091-001
9
8
4
6
2
12
14
7
9
10
19 & 11
9
3 Behind Front Panel
5
18
15
16
Locator
Post
3
21
19 & 11 22 & 23
19 & 11
15
14
1
5
24
13
