Dexter Laundry A Series Service Procedures And Parts Data

Part # 0995-093-001 (1/06) Dexter reserves the right to change part numbers and/or specifi cations without notice.
© 2006 The Dexter Company • 2211 W. Grimes Ave, Fairfi eld, IA 52556, U.S.A. • 1-800-524-2954 • www.dexterlaundry.com
Reproduction of this manual in any form without express written permission is forbidden.
Dexter Industrial V-Series Washer Specifications
Dexter
Industrial
(OPL)
V
-
Series
Washer
Specifications
Part
#
:
0995
-
093
-
001
CAPACITY Load Size Double Load
Dry Weight Capacity 18 - 20 lbs. 8.11 kg Cylinder Diameter 21” 53.3 cm Cylinder Depth 13.5” 34.3 cm Cylinder Volume 2.7 cu ft 76.6 dm3 DIMENSIONS Cabinet Height 43.88” 111.44 cm Cabinet Width 26” 66.04 cm Overall Depth 24.81” 63.02 cm Floor to Door Bottom 15” 38.1 cm Door Opening 12.25” 31.1 cm WASHING/EXTRACTION High Extract Speed 100 G-Force 579 RPM Intermed. Extract Speed 60 G-Force 449 RPM Washing Speed 55 RPM Motor Size 1 HP . 0.75 Kw ELECTRICAL Electrical Phase Single Voltage (60 Hz) 120 volts Running (Amps) 13 Circuit Protection (Amps) 20 amp Wire Size Cord Provided Service (Single Phase) Cord Provided Service (Three Phase) NA WATER Water Inlet Size 3/4” 19mm Flow Rate (per minute) 9 gal 34.06 L Pressure (min/max) 30-120 psi 207-827 Kpa Drain Diameter (O.D.) 2.25” 5.7 cm Floor to Center of Drain 6” 15.24 cm INSTALLATION Net Weight 326 lbs 146.8 kg Space Between Machines 1/2” (min) 1.27 cm Space Behind Machines 24” (min) 60.96 cm Concrete Thickness 6” (min) 15.24 cm
Double Load 18 - 20 lbs. 8.11 kg 21” 53.3 cm 13.5” 34.3 cm 2.7 cu ft 76.6 dm3 43.88” 111.44 cm 26” 66.04 cm 24.81” 63.02 cm 15” 38.1 cm 12.25” 31.1 cm 100 G-Force 579 RPM 60 G-Force 449 RPM 55 RPM 1 HP . 0.75 Kw Single or Three 208-240 volts 4 15 amp 14 gauge 2 wire + ground 3 wire + ground 3/4” 19mm 9 gal 34.06 L 30-120 psi 207-827 Kpa 2.25” 5.7 cm 6” 15.24 cm 326 lbs 146.8 kg 1/2” (min) 1.27 cm 24” (min) 60.96 cm 6” (min) 15.24 cm
Triple Load 25 - 30 lbs. 11.26 kg 25” 63.5 cm 14.13” 35.9 cm 4 cu ft 113.4 dm3 48.25” 122.56 cm 29.88” 75.88 cm
27.38” 69.5 cm 16” 40.64 cm 15.25” 38.74 cm 100 G-Force 532 RPM 60 G-Force 412 RPM 50 RPM 2 HP 1.5 Kw Single or Three 208-240 volts 6.2 15 amp 14 gauge 2 wire + ground 3 wire + ground 3/4” 19mm 9 gal 34.06 L 30-120 psi 207-827 Kpa 3” 7.62 cm 5” 12.7 cm 464 lbs 210 kg 1/2” (min) 1.27 cm 24” (min) 60.96 cm 6” (min) 15.24 cm
Maxi Load 40 - 45 lbs. 18 kg 25” 63.5 cm 21.13” 53.7 cm 6 cu ft 170.1 dm3 49.75” 126.37 cm 29.88” 75.88 cm 36” 91.44 cm 16” 40.64 cm 15.25” 38.74 cm 100 G-Force 532 RPM 60 G-Force 412 RPM 50 RPM 2 HP 1.5 Kw Single or Three 208-240 volts 6.2 15 amp 14 gauge 2 wire + ground 3 wire + ground 3/4” 19mm 9 gal 34.06 L 30-120 psi 207-827 Kpa 3” 7.62 cm 5” 12.7 cm 631 lbs 286.2 kg 1/2” (min) 1.27 cm 24” (min) 60.96 cm 6” (min) 15.24 cm
Mega Load 55 - 60 lbs. 24.8 kg 30” 76.2 cm 22” 55.9 cm 9 cu ft 255.1 dm3 54” 137.16 cm 34.39” 87.31 cm 38.75” 98.43 cm 18.5” 46.99 cm 15.25” 38.74 cm 100 G-Force 485 RPM 60 G-Force 375 RPM 43 RPM 3 HP 2.24 Kw Single or Three 208-240 volts 8.4 20 amp 12 gauge 2 wire + ground 3 wire + ground 3/4” 19mm 9 gal 34.06 L 30-120 psi 207-827 Kpa 3” 7.62 cm 7.5” 19.05 cm 1082 lbs 491 kg 1/2” (min) 1.27 cm 24” (min) 60.96 cm 8” 20.3 cm
Magnum Load 75 - 80 lbs. 33.8 kg 30” 76.2 cm 28” 71.2 cm 11.5 cu ft 326 dm3 58” 147.30 cm 34.39” 87.31 cm 45.25” 114.94 cm 20.5” 52.07 cm 15.25” 38.74 cm 100 G-Force 485 RPM 60 G-Force 375 RPM 43 RPM 3 HP 2.24 Kw Single or Three 208-240 volts 8.4 20 amp 12 gauge 2 wire + ground 3 wire + ground 3/4” 19mm 12 gal 45.41 L 10-130 psi 69-896 Kpa 3” 7.62 cm 8” 20.3 cm 1153 lbs 523 kg 1/2” (min) 1.27 cm 24” (min) 60.96 cm 8” 20.3 cm
WCVD18HCS-10 120 Volt
WCVD18HCS-12 208-240 Volt
WCVD25HCS-12
WCVD40HCS-12
WCVD55HCS-12 WCVD75HCS-12
