OPERATOR’S MANUAL
GAC® 2100 Grain Analysis Computer (Blue, Gray, Agri Models)
11001-1688-201609
TEST UNIT PERFORMANCE 71
3. Press the Next Page key to view PAGE 2 of the DIAGNOSTIC MODE.
The display screen is divided into two columns: 5 kHz and 2 MHz
(Figure 58).
– 5 kHz (D1) – Left half of screen
1: Vc - Voltage of 5 kHz oscillator.
2: Vc-Vn - Voltage of 5 kHz oscillator minus null voltage.
3: Vsc - Voltage of 5 kHz oscillator with on-board test
network engaged.
4: Vsc - Vn - Voltage of 5 kHz oscillator with the on-board test
network engaged minus null voltage.
– 2 MHz (D2) – Right half of screen
5: Vc - Voltage of 2 MHz oscillator.
6: Vc - Vn - Voltage of 2 MHz oscillator minus null voltage.
7: Vsc - Voltage of 2 MHz oscillator with on-board test
network engaged.
8: Vsc - Vn - Voltage of 2 MHz oscillator with on-board test
network engaged minus null voltage.
4. When finished, press the Previous Page key twice to return to the
Tests menu.
Figure 59
Diagnostic Mode Printout of Page 1
Figure 60
Diagnostic Mode Printout of Page 2
VNULL: 0,0496
VTEMP: 1,1838
CWGT: 38908
CE/F: 1,05377
S/N: 0261-2360
SCD1: 378
SCD2: 2499
NEC: 0,04941
KEC: 1,50218
KSC: 1,22889
MEC: 1,40597
MSC: 0,43373
TEMP: 18,26
5 KHZ VC: 1,5024
5 KHZ VC-VN: 1,4528
5 KHZ VSC: 1,2291
5 KHZ VSC-VN: 1,1795
2 MHZ VC: 1,4943
2 MHZ VC-VN: 1,4446
2 MHZ VSC: 0,4416
2 MHZ VSC-VN: 0,3920
Previous Page Key
Next Page key
To Next Page
