- 32 -
DI-80 USER MANUAL
1.11 SWITCHING PLATFORM
Switching platform is available in both Weighing Mode and Counting by press the [SWITCH] key to switch between Scale 1 &
Scale 2. To enable this function, SPEC 25 bit 1 must set to "1" and both scales must be calibrated in advance.
Note: For Weighing Mode, not allow to changing scale when Memory lamp is lighter up.
For Counting Mode, allow to changing scale when Memory lamp is lighter up.
Stability check when changing scale can be set at SPEC 38 bit 0.
Re-zero when changing scale can be set at SPEC 39 bit 0 (Effective only when SPEC 38 bit 0 set to "0" and SPEC
00 bit 2 set to "0").
For example: Change scale 1 to scale 2 in Weighing Mode.
OPERATION KEY DISPLAY
¼0»
NET
kg
0. 0 0 0
S T E A T I T E - C 3 H 5
T
1. At Weighing Mode, enter the
existing PLU Number by
numeric key (Ex. 123) and
press [PLU] key.
¼0»
NET
kg
0. 0 0
S T E A T I T E - C 3 H 5
T
2. Press [SWITCH] key to
change scale form scale 1 to
scale 2.
Scale 2 Indicator lighter up.
¼0»
NET
kg
0. 0 0
2. 0000 0
T
Pcs
3. Press [MODE] key to change
Weight Mode to Counting
Mode.
NET
kg
20. 0 0
2. 0000 1 0000
T
T
Pcs
4. Place the product on Scale 2
(Ex. 20kg).
Pcs
tot A L
Q U A N T I T Y 1 0 0 0 0
T
T T
5. Press [+] key.
To Next Page
