Serial port
IX14 User Guide
167
where value is in milliseconds (ms) or seconds (s). The maximum value is 60s.
14. Set the end pattern. The packet is sent when this pattern is received from the serial port:
(config)>serial port1 framing end_pattern backslash-escaped-string
(config)
15. Set the strip end pattern if you want to remove the end pattern from the packet before it is
sent:
(config)>serial port1 framing strip_pattern true
(config)
16. Set the UDPport:
(config)> serial port1 udp port port
(config)>
The default is 4001.
17. (Optional) Enter a string that should be added at the beginning of each packet:
(config)> serial port1 udp socketid backslash-escaped-string
(config)>
18. Configure the remote sites to which you want to send data. If you do not specify any
destinations, the IX14 send new data to the last hostname and port from which data was
received. To add a destination:
i. Add a destination:
(config)> add serial port1 upd destination end
(config serial port1 udp destination 0)>
ii. (Optional) Enter a description of the destination:
(config serial port1 udp destination 0)> description string
(config serial port1 udp destination 0)>
iii. Set the host name or IP address of the remote site to which data should be sent:
(config serial port1 udp destination 0)>hostname hostanme-or-IP-
address
(config serial port1 udp destination 0)>
iv. Set the port number of the remote site to which data should be sent:
(config serial port1 udp destination 0)> port port
(config serial port1 udp destination 0)>
19. Save the configuration and apply the change:
(config)> save
Configuration saved.
>
