Firewall Configure Quality of Service options
IX14 User Guide
265
n
Outbound provides an example of matching packets as they are routed from the device onto
the WAN interface.
n
Inbound provides an example of matching packets as they are routed from the device onto a
LAN interface.
These example bindings are disabled by default.
Enable the preconfigured bindings
WebUI
1. Log into the IX14 WebUI as a user with full Admin access rights.
2. On the menu, click System. Under Configuration, click Device Configuration.
The Configuration window is displayed.
3. Click Firewall > Quality of Service.
4. Click to expand either Outbound or Inbound.
5. Enable the binding.
6. Select an Interface.
7. Examine the remaining default settings and modify as appropriate for your network.
8. Click Apply to save the configuration and apply the change.
Command line
