Services Location information
IX14 User Guide
370
Additional configuration items
n
Additional remote hosts to which the location messages will be forwarded.
n
Location update interval, which determines how often the device will forward location
information to the remote hosts.
n
A description of the remote hosts.
n
Specific types of NMEA or TAIP messages that should be forwarded.
n
If the message protocol is NMEA, configure a talker ID to be used for all messages.
n
Text that will be prepended to the forwarded message.
n
A vehicle ID that is used in the TAIP ID message and can also be prepended to the forwarded
message.
Configure the IX14 device to forward location information:
WebUI
1. Log into the IX14 WebUI as a user with full Admin access rights.
2. On the menu, click System. Under Configuration, click Device Configuration.
The Configuration window is displayed.
3. Click Services > Location > Destination servers.
4. For Add destination server, click .
5. (Optional) For Label, type a description of the location destination server.
6. For Destination server, enter the hostname or IP address of the remote host to which location
messages will be sent.
7. For Destination server port, enter the UDP or TCP port on the remote host to which location
messages will be sent.
8. For Communication protocol, select either UDP or TCP.
