Virtual Private Networks (VPN) Generic Routing Encapsulation (GRE)
IX14 User Guide
618
GRE tunnels are enabled by default. To disable:
(config vpn iptunnel gre_example)> enable false
(config vpn iptunnel gre_example)>
4. Set the local endpoint to the GREendpoint interface created in Task One, for example:
(config vpn iptunnel gre_example)> local /network/interface/gre_endpoint
(config vpn iptunnel gre_example)>
To view configured interfaces and proper syntax:
(config vpn iptunnel gre_example)> local ?
Local endpoint: The local network interface to connect to peer device.
Format:
/network/interface/aview
/network/interface/defaultip
/network/interface/defaultlinklocal
/network/interface/gre_endpoint
/network/interface/lan
/network/interface/loopback
/network/interface/wan
Current value:
(config vpn iptunnel gre_example)>
5. Set the IP address of the GRE endpoint on the remote peer:
(config vpn iptunnel gre_example)> remote ip_address
(config vpn iptunnel gre_example)>
6. (Optional) Set a key that will be inserted in GRE packets created by this tunnel.
The key must match the key set by the remote endpoint.
(config vpn iptunnel gre_example)> key value
(config vpn iptunnel gre_example)>
where value is an interger between 0 and 4294967295, or an IP address.
7. (Optional) Enable the device to reply to Cisco GRE keepalive packets:
(config vpn iptunnel gre_example)> keepalive true
(config vpn iptunnel gre_example)>
8. Save the configuration and apply the change:
(config vpn iptunnel gre_example)> save
Configuration saved.
>
9. Type exit to exit the Admin CLI.
Depending on your device configuration, you may be presented with an Access selection
menu. Type quit to disconnect from the device.
