Chapter 5: The Digi 002 Rack Front Panel 47
chapter 5
The Digi 002 Rack Front Panel
The Digi 002 Rack front panel includes controls
for Inputs 1–4, options for routing outputs and
monitoring alternate input sources, and indica-
tors for session sample rate, connections status,
and MIDI data.
Figure 2. Digi 002 Rack front panel
Mic/Line/Inst
input controls
Status Indicators
Monitor section
Power switch
