Getting Started with Digi 002 & Digi 002 Rack106
Working with Effects
In Channel view, the controls for the Digi 002
EQ and Dynamics effects are displayed across
the Channel Scribble Strips.
EQ Controls
To access EQ controls for a track:
1 Press the EQ switch in the Channel View area
above the Channel Scribble Strips.
2 Press the Channel Select switch on the chan-
nel whose EQ controls you want to display.
The onboard EQ controls are distributed across
the Channel Scribble Strips as shown in
Table 10. The second row of the table shows the
function of the Rotary Encoders, and the bot-
tom row of the table shows the function of the
Channel Select switches in this view.
3 When you are finished setting the EQ con-
trols, return to Home View by pressing the Pan
switch in the Console View area.
While EQ controls are displayed, you can bypass
EQ processing by pressing the Master Bypass
switch in the Channel View area. The Master By-
pass switch bypasses all 3 bands of EQ for the se-
lected channel.
To bypass EQ controls for a track:
1 Press the EQ switch in the Channel View area
above the Channel Scribble Strips.
2 Press the Channel Select switch on the chan-
nel whose EQ controls you want to bypass.
3 Press the Master Bypass switch while in Chan-
nel View. The switch flashes to indicate that the
displayed EQ is currently bypassed.
Table 10. EQ controls in Digi 002 Stand-alone mode
Display Inpt > F or ∼F> G or ~G ^ F ^ Q ^ G < F or ¬ F <G or ¬ G
Rotary
Encoder
Input
Gain
Low Shelf
Frequency
or
High Pass
Frequency
Low Shelf
Gain
Peak
Frequency
Peak Q Peak Gain High Shelf
Frequency
or
Low Pass
Frequency
High Shelf
Gain
Channel
Select
Toggle
between
filters
Bypass
Low Band
Bypass
Mid-Band
Toggle
between
filters
Bypass
High Band
