Getting Started with Digi 002 & Digi 002 Rack108
Working with Sends
In Stand-alone mode, each Input channel has
four fixed sends, with the first two dedicated to
the internal Delay and Reverb processing of
Digi 002.
To display and edit the sends to the Delay:
1 Press the Send switch in the upper left-hand
corner of the Digi 002 unit, in the Console View
area.
2 Press the Send A switch (located immediately
below the Send switch you just pressed). The ro-
tary encoders show the levels for the corre-
sponding sends on each track.
3 Adjust the rotary encoders as desired to send
signal to the onboard Delay.
4 Press the Master Fader switch, located to the
left of the Navigation and Transport section.
The return track for Send A is named Dly.
5 Adjust the fader volume and pan position for
the return track.
6 Press the Master Fader switch again to return
to the previous view, or press the Pan switch to
return to Home View.
To display and edit the sends to the Reverb:
1 Press the Send switch in the upper left-hand
corner of the Digi 002 unit, in the Console View
area.
2 Press the Send B switch. The rotary encoders
show the levels for the corresponding sends on
each track.
3 Adjust the rotary encoders as desired to send
signal to the onboard Reverb.
4 Press the Master Fader switch, located to the
left of the Navigation and Transport section.
The stereo return tracks for Send B are named
RvbL and RvbR.
5 Adjust the fader volume for the return tracks.
6 Press the Master Fader switch again to return
to the previous view, or press the Pan switch to
return to Home View.
