Digital Projection 7000 Series User Manual

Digital Projection E-Vision 7000 Series Supported Signal Input Modes Connection Guide
16
Rev B May 2013
Supported Signal Input Modes
Signal Resolution Refresh
Rate
( Hz )
Total
number
of lines
Horizontal
Frequency
(kHz)
3D
VIDEO /
S-VIDEO
COMPONENT
COMPUTER 1
(VGA)
COMPUTER 2
(RGB/YCbCr)
COMPUTER 3
(DVI-I)
SDTV 480i 720 x 480 59.94 525 15.73
ü ü ü
576i 720 x 576 50 625 15.63
ü ü ü
HDTV 480p 720 x 480 59.94 525 31.47
ü ü ü
576p 720 x 576 50 625 31.25
ü ü ü
720p50 1280 x 720 50 750 37.50
ü ü ü
720p60 1280 x 720 60 750 45.00
ü ü ü
1080i50 1920 x 1080 50 1125 28.13
ü ü ü
1080i60 1920 x 1080 60 1125 33.75
ü ü ü
1080p50 1920 x 1080 50 1125 56.25
ü ü ü
1080p60 1920 x 1080 60 1125 67.5
ü ü ü
COMPUTER 480p 640 x 480 59.9 526 31.5
ü ü ü
VGA72 640 x 480 72.8 521 37.9
ü ü ü
VGA75 640 x 480 75 500 37.5
ü ü ü
VGA85 640 x 480 85 509 43.3
ü ü ü
SVGA56 800 x 600 56.3 625 35.2
ü ü ü
SVGA60 800 x 600 60.3 629 37.9
ü ü ü ü
SVGA72 800 x 600 72.2 666 48.1
ü ü ü
SVGA75 800 x 600 75 625 46.9
ü ü ü
SVGA85 800 x 600 85.1 631 53.7
ü ü ü
SVGA120 800 x 600 120.6 663 80.0
ü ü
SVGA120 800 x 600_RB 120 611 73.3
ü ü
SVGA120 800 x 600 119.9 700 83.9
ü ü
XGA60 1024 x 768 60 807 48.4
ü ü ü ü
XGA70 1024 x 768 70.1 806 56.5
ü ü ü
XGA75 1024 x 768 75 800 60
ü ü ü
XGA120 1024 x 768 120 806 96.7
ü ü
XGA120 1024 x 768_RB 120 813 97.6
ü ü
XGA120 1024 x 768 119.8 823 98.6
ü ü
continued on next page...
