TECHNICAL REFERENCE MANUAL
3.4 Measuring characteristics
Multiple measuring characteristics are available in the FLS-C measuring devices to meet different requirements for various applications. With
these measuring characteristics measuring rate and accuracy can be optimized for special requirements.
The FLS-C measuring device at factory settings has an accuracy of ±1 mm (FLS-C(H) 10) respectively ±3 mm (FLS-C(H) 30) at 2σ. Measuring
rate depends on environmental conditions such as target surface, distance, background light (e.g. sun light), etc. Good environmental
conditions increase measuring rate (e.g. white target surface or orange reflective target plate and dark environment).
3.4.1 Measuring characteristics overview
Available in DLS-C(H)
Available in FLS-C(H)
Measuring
character-
istic
Measuring
rate
Typical accuracy @
2σ
Description
Error behavior
1)
User Commands
2)
FLS-C(H)
10
FLS-C(H)
30
Normal Commands
2)
Normal
(factory
setting)
max. 10
Hz
3)
1)
±1 mm ±3 mm
Measuring range on natural surface: typical 65 m
Configuration command: sNuc+0+0
4)
 
A
 
Fast max. 20 Hz
1)
±2 mm ±6 mm
Increased measuring rate up to 20 Hz.
Configuration command: sNuc+0+1
4)
 
A
 
Precise max. 6 Hz
1)
~±0.8 mm ~±2.4 mm
Increased accuracy of ±0.8 mm
Surveying applications, short range applications etc.
Configuration command: sNuc+0+2
4)
 
A
 
Natural
surface
max. 6Hz,
can drop to
0.25Hz @ up
to approx.
80m
~±5 mm
@ up to
approx.
80m
~±15 mm
@ up to
approx.
80m
Increased measuring range on natural surfaces:
typical 80 meters
Measuring against far away natural surfaces or bad reflective
surfaces such as black synthetic granules, etc.
Configuration command: sNuc+0+3
4)
 
A
 
Timed
user
programmed
DLS: ≤ 6Hz,
FLS: ≤ 35Hz
variable variable
The device does not check the signal condition to ensure the
specified accuracy is reached, a measurement value is transferred
to the output at a defined measuring rate.
This mode serves for applications where the accuracy is not
important but the reaction time is critical
Configuration command: sNuc+1+1
4)
 
A
 
Moving
Target
250Hz,
SSI can poll
with up to
500Hz
±1 mm ±3 mm
The device measures to a continuously moving target and the
distance changes without any jumps.
This measurement characteristic supervises the max speed,
checks for distance jumps and includes a special filter to
eliminate errors occurring for only a very short time.
Configuration command: sNuc+2+0
4)
(with error freezing)
sNuc+2+1
4)
(without error freezing)
 
B
 
1) The behavior in case of an error depends on the configuration. See 3.4.3 Error behavior on page 14
2) Changed characteristics do not influence all commands
3) Good environmental conditions (e.g. white target surface or orange reflective target plate and dark environment).
4) For the description of the command see 9.3.2 Measuring characteristic configuration (sNuc) on Page 34
Distance Laser Sensor Page 12/53
