9.3.2 Measuring characteristic configuration (sNuc)
Multiple measuring characteristic available in the FLS-C measuring devices meet different requirements for various applications. With these
measuring characteristics measuring rate and accuracy can be optimized for special requirements.
While on factory settings, the FLS-C measuring device has an accuracy of ±1 mm 2σ (FLS-C(H) 10) respectively ±3 mm 2σ (FLS-C(H) 30).
Measuring rate depends on environmental conditions such as target surface, distance, background light (e.g. sun light), etc. Good
environmental conditions increase measuring rate (e.g. white target surface or orange reflective target plate and dark environment).
For a detailed description of the different measuring characteristics see 3.4 Measuring characteristics on page 12.
The configuration command sNuc is applied to the special user commands and to the standard
commands.
Set command Get command
Command
sNuc+a+b<trm> sNuc
Return successful
gNuc+xxxxxxxx+yyyyyyyy<trm>
gNuc+xxxxxxxx+yyyyyyyy<trm>
Return error
gN@Ezzz<trm>
gN@Ezzz<trm>
Parameters
N Device ID
a = 0 b = 0: Normal
1: Fast
2: Precise
3: Natural surface
a = 1 b = 1: Timed
a = 2 b = 0: Moving target characteristic with error freezing
Every error will be preserved. For an error reset, the measurement must
be restarted according to the configured operation mode.
(See 3.4.3 Error behavior on page 14)
1: Moving target characteristic without error freezing
Distance jumps or unfavorable signal conditions may cause a temporary
or permanent error.
Temporary error
As soon as the FLS is able to determine a new distance value, the error
will disappear and the output will show the new distance value. The
shortest possible time to display an error is 4..5ms.
Permanent error
The FLS is not able to determine a distance anymore. The error will be
shown with an output rate of up to 250Hz. For an error reset, the
measurement must be restarted according to the configured
operation mode.
(See 3.4.3 Error behavior on page 14)
zzz Error code
Configuration parameters need to be saved (See 9.3.13 Save configuration parameters (sNs) on page 40)
Distance Laser Sensor Page 34/53
