Dimetix DLS-C 15 User Manual

TECHNICAL REFERENCE MANUAL
9.6 Error codes
No. Format Meaning and elimination
203
@E203
Wrong syntax in command, prohibited parameter in command entry or non-valid result
210
@E210
Not in tracking mode, start tracking mode first
211
@E211
Sampling too fast, set the sampling time to a larger value
212
@E212
Command cannot be executed, because tracking mode is active, first use command sNc to stop tracking
mode
220
@E220
Communication error, check configuration settings
230
@E230
Distance value overflow caused by wrong user configuration. Change user offset (and/or user gain)
231
@E231
Wrong mode for digital input status read, activate DI1
232
@E232
Digital output 1 cannot be set if configured as digital input
233
@E233
Number cannot be displayed. (Check output format)
234
@E234
Distance out of range
236
@E236
Digital output manual mode cannot be activated when configured as digital input
252
@E252
Temperature too high
(contact Dimetix if error occurs at room temperature)
253
@E253
Temperature too low
(contact Dimetix if error occurs at room temperature)
254
@E254
Bad signal from target, It takes too long to measure according distance. Use white surface or reflective
target.
255
@E255
Received signal too weak or target lost in moving target characteristic
(Use different target and distances, if the problem persists, please contact Dimetix)
256
@E256
Received signal too strong
(Use different target and distances, if the problem persists, please contact Dimetix)
258
@E258
Power supply voltage is too high
259
@E259
Power supply voltage is too low
260
@E260
Distance cannot be calculated because of ambiguous targets. Use clearly defined targets to measure the
distance.
263
@E263
Too much light, use only Dimetix reflective target plate.
In moving target characteristic, distance jump occured
264
@E264
Too much light, measuring on reflective targets not possible
330
@E330
Acceleration of the target too strong or distance jump (in moving target characteristic only)
331
@E331
Over speed of target (in moving target characteristic only)
360
@E360
Configured measuring time is too short, set longer time or use 0
361
@E361
Configured measuring time is too long, set shorter time
not listed Hardware failure (Contact Dimetix)
Before contacting Dimetix, please collect as much information as possible.
Distance Laser Sensor Page 47/53
